ACT Wireless Optical Mouse AC5105 User Manual

1. Ifihan

Thank you for choosing the ACT AC5105 Wireless Optical Mouse. This device is designed for comfortable and efficient use at home, in the office, or while traveling. It features a compact Nano USB receiver and an intelligent power-saving mode to extend battery life. This manual provides detailed instructions for setup, operation, and maintenance of your new wireless mouse.

2. Package Awọn akoonu

• ACT AC5105 Wireless Optical Mouse
• Nano USB olugba
• 1 x AA Batiri (pẹlu)

3. Eto Itọsọna

1. Fi Batiri sii:

   Open the battery compartment cover located on the underside of the mouse. Insert the included AA battery, ensuring correct polarity (+/-). Close the battery compartment cover securely.



   Figure 3.1: Battery and Nano Receiver Storage

   This image illustrates the underside of the mouse with the battery compartment open, showing where to insert the AA battery and store the Nano USB receiver. The on/off switch is also visible.

2. Connect the Nano USB Receiver:

   Remove the Nano USB receiver from its storage slot inside the battery compartment. Plug the receiver into an available USB-A port on your computer. Your operating system will automatically detect and install the necessary drivers.
3. Agbara Lori Asin:

   Locate the On/Off switch on the underside of the mouse and slide it to the "ON" position. The mouse is now ready for use.

4. Awọn ilana Iṣiṣẹ

4.1 Ipilẹ Awọn iṣẹ

• Tẹ osi: Primary function, typically for selecting items or opening links.
• Tẹ-ọtun: Secondary function, typically for opening context menus.
• Yi lọ Kẹkẹ: Yi lọ si oke tabi isalẹ nipasẹ awọn iwe aṣẹ ati web pages. The scroll wheel can also be pressed for a middle-click function.

Figure 4.1: Mouse Features Overview

This diagram highlights key features such as silent click buttons, the scroll wheel, the USB-A wireless receiver, the 1600 DPI optical sensor, and the use of recycled materials in its construction.

4.2 DPI Atunṣe

The ACT AC5105 mouse features an adjustable DPI (Dots Per Inch) setting, allowing you to change the cursor speed and sensitivity. You can cycle through 800, 1200, and 1600 DPI settings by pressing the DPI switch button located behind the scroll wheel.

• 800 DPI: Slower cursor movement, suitable for precise tasks.
• 1200 DPI: Standard cursor movement, suitable for general use.
• 1600 DPI: Faster cursor movement, suitable for quick navigation across large screens.

Figure 4.2: DPI Switch Location

This image shows the mouse in use on a desk, highlighting the DPI switch button for adjusting sensitivity between 800, 1200, and 1600 DPI.

4.3 Ipo Ifipamọ Agbara

The mouse is equipped with an intelligent power-saving feature. If the mouse is inactive for a period, it will automatically enter standby mode to conserve battery power. To wake the mouse, simply move it or click any button.

For extended periods of non-use, it is recommended to switch the mouse off using the On/Off switch on the underside of the device.

5. Itọju

• Ninu: Lo asọ asọ ti o gbẹ lati nu asin naa. Yago fun lilo awọn kẹmika lile tabi awọn ohun elo abrasive.
• Rirọpo Batiri: When the mouse performance degrades or it stops responding, replace the AA battery with a new one. Follow the steps in Section 3.1.
• Ibi ipamọ: When not in use, especially during travel, you can store the Nano USB receiver inside the mouse's battery compartment to prevent loss.

6. Laasigbotitusita

7. Awọn pato

Àwòrán 7.1: Ìwọ̀n Àákù

This image provides a top-down and side view of the mouse, clearly indicating its physical dimensions: 105mm in length, 65mm in width, and 35mm in height.

8. Atilẹyin ọja ati Support

ACT products are manufactured to high quality standards. This product comes with a 2-year warranty from the date of purchase against defects in materials and workmanship.

For technical support, warranty claims, or further assistance, please refer to the official ACT webaaye ayelujara tabi kan si alagbata agbegbe rẹ.

Jọwọ ṣe idaduro ẹri rira rẹ fun awọn idi atilẹyin ọja.
