Ọrọ Iṣaaju
O ṣeun fun riraasing the KTC H27S17 27-inch WQHD 180Hz Curved Gaming Monitor. This manual provides essential information for the safe and efficient use of your new monitor. Please read it thoroughly before use and retain it for future reference.
Ọja Pariview Fidio
Fidio: Ifihan fidio ọja osise kanasing the key features and design of the KTC H27S17 27-inch Curved Gaming Monitor.
Package Awọn akoonu
Daju pe gbogbo awọn nkan ti a ṣe akojọ rẹ si isalẹ wa ninu package rẹ:
- Okun agbara
- Okun DisplayPort
- Adapter agbara
- Atẹle Iduro
- Ipilẹ Iduro
- Driver CD (or download link)
- Iṣagbesori skru
- Instruction Manual (Japanese version)
- Quick Bẹrẹ Itọsọna
- Kaadi atilẹyin ọja
Awọn ilana iṣeto
1. Nto Iduro
Attach the stand base to the monitor stand using the provided screws. Then, securely attach the assembled stand to the back of the monitor.
Image: The KTC H27S17 monitor fully assembled with its stand, viewed lati iwaju.
2. Sísopọ̀ mọ́ Orísun Agbára
Connect the power adapter to the monitor's DC input port, then plug the power cable into a wall outlet.
3. Sísopọ̀ mọ́ ẹ̀rọ kan
Use the appropriate cable (DisplayPort or HDMI) to connect your computer or gaming console to the monitor. Ensure the cable is securely connected to both the monitor and your device.
Aworan: Ẹyin view of the monitor showing the various input ports including DC, USB, HDMI, DisplayPort, and headphone jack.
4. Fífi VESA sori ẹrọ (Àṣàyàn)
The monitor supports VESA 100mm x 100mm mounting. If using a VESA mount, remove the stand and attach the monitor to your VESA-compatible arm or wall mount using appropriate screws.
Image: Diagram illustrating the VESA 100x100mm mounting pattern and tilt adjustment range on the back of the monitor.
Awọn ilana Iṣiṣẹ
Titan / Paa
Tẹ bọtini agbara, ti o maa n wa ni ẹhin tabi isalẹ ti iboju naa, lati tan tabi pa a. Ina ifihan agbara yoo tan nigbati iboju naa ba wa ni titan.
Lori-iboju Ifihan (OSD) Akojọ aṣyn
Use the joystick or buttons on the monitor to navigate the OSD menu. This menu allows you to adjust various display settings such as brightness, contrast, color temperature, input source, and gaming features.
Aṣayan Orisun titẹ sii
If multiple devices are connected, use the OSD menu to select the desired input source (HDMI 1, HDMI 2, DisplayPort 1, DisplayPort 2).
Ifihan Awọn ẹya ara ẹrọ
Curved Display (1500R)
Ìtẹ̀sí 1500R náà ń fúnni ní ohun tó wúni lórí viewing experience, reducing eye strain during extended use by matching the natural curve of the human eye.
Image: A curved monitor displaying a vibrant image, highlighting the 1500R curvature for an immersive experience.
WQHD Resolution (2560x1440)
Experience detailed visuals with WQHD (2560x1440) resolution, offering approximately 1.7 times the pixel density of Full HD displays.
Image: A monitor displaying a high-resolution image, emphasizing the clarity of WQHD (2560x1440) compared to lower resolutions.
High Refresh Rate (180Hz) and Fast Response Time (1ms MPRT)
The 180Hz refresh rate and 1ms (MPRT) response time ensure smooth, blur-free visuals, crucial for fast-paced gaming and action scenes.
Image: A split screen comparison on the monitor, demonstrating the difference between 180Hz/1ms and 60Hz/5ms, highlighting reduced motion blur.
Vibrant Color Reproduction and HDR10
With sRGB 132%, DCI-P3 104%, Adobe RGB 112% color volume, and HDR10 support, the monitor delivers accurate and vivid colors with enhanced contrast between bright and dark areas.
Image: A monitor displaying a colorful scene, illustrating the wide color gamut and high contrast ratio (5000:1).
Image: A monitor showing a scene with HDR10 enabled, demonstrating improved dynamic range and detail in both bright and dark areas.
Adaptive Sync Technology
Adaptive Sync (FreeSync and G-Sync compatible) eliminates screen tearing and stuttering, providing a fluid gaming experience.
Image: A split screen comparison on the monitor, showing the difference between Adaptive Sync OFF (screen tearing) and ON (smooth image).
Oju Itọju Awọn ẹya ara ẹrọ
The monitor includes Flicker-Free technology and a Low Blue Light mode to reduce eye strain during prolonged use.
Image: Illustrations demonstrating Flicker-Free technology and Low Blue Light mode, designed to reduce eye fatigue.
Asopọmọra
The KTC H27S17 monitor offers multiple connectivity options:
- 2 x HDMI 2.0: Supports WQHD (2560x1440) at 144Hz.
- 2 x DisplayPort 1.4: Supports WQHD (2560x1440) at 180Hz.
- 1 x USB 2.0: Fun awọn igbesoke firmware nikan.
- 1 x 3.5mm Headphone Jack: Fun igbejade ohun.
- 1 x DC Input: Fun asopọ agbara.
Aworan: Alaye view of the monitor's rear panel, highlighting the DC input, USB port, HDMI ports, DisplayPort inputs, and headphone jack.
Physical Adjustments
Titunse pulọọgi
The monitor stand allows for tilt adjustment from -5 to 15 degrees, enabling you to find an optimal viewing igun fun itunu.
Image: Diagram illustrating the tilt adjustment range of the monitor stand.
VESA ibamu
The monitor is compatible with VESA 100mm x 100mm mounting standards, allowing for flexible installation with monitor arms or wall mounts.
Itoju
Ninu iboju
Rọra nu iboju naa pẹlu asọ ti ko ni lint. Fun awọn ami alagidi, fẹẹrẹ dampFi omi tàbí omi ìfọṣọ ìbòjú bo aṣọ náà. Yẹra fún lílo àwọn kẹ́míkà líle tàbí àwọn ohun èlò ìfọṣọ.
Cleaning the Monitor Body
Wipe the monitor body with a soft, dry cloth. Do not use liquid cleaners directly on the monitor.
Ibi ipamọ
When not in use for extended periods, store the monitor in a cool, dry place, away from direct sunlight and extreme temperatures.
Laasigbotitusita
Ti o ba pade awọn ọran pẹlu atẹle rẹ, tọka si awọn solusan ti o wọpọ wọnyi:
- Ko si Agbara: Ensure the power cable and adapter are securely connected and the power outlet is functional.
- Ko si ifihan agbara: Verify that the input cable (HDMI/DisplayPort) is correctly connected to both the monitor and the source device. Select the correct input source via the OSD menu.
- Aworan ti o nmi/ti daru: Check cable connections. Ensure your graphics card drivers are up to date. Try adjusting the refresh rate in your device's display settings.
- Awọn piksẹli ti o ku: While rare, a small number of dead pixels may be within manufacturing tolerances. Refer to the warranty policy for details.
- Audio Issues (Headphone Jack): Ensure headphones are fully plugged in. Check audio settings on your connected device.
For further assistance, please contact KTC customer support.
Awọn pato
| Ẹya ara ẹrọ | Sipesifikesonu |
|---|---|
| Brand | CTC |
| Awoṣe | H27S17 |
| Iwon iboju | 27 inches |
| Ipinnu | WQHD (2560 x 1440 pixels) |
| Apakan Ipin | 16:9 |
| ìsépo | 1500R |
| Panel Iru | VA |
| Oṣuwọn sọtun | 180 Hz |
| Akoko Idahun | 1 ms (MPRT) |
| Ipin Itansan | 5000:1 |
| Imọlẹ | 300 cd/m² |
| Awọ Gamut | sRGB 132% / DCI-P3 104% / Adobe RGB 112% |
| HDR atilẹyin | HDR10 |
| Amuṣiṣẹpọ Adaptive | FreeSync, G-Sync Compatible |
| Asopọmọra | 2x HDMI 2.0, 2x DisplayPort 1.4, 1x USB 2.0 (Upgrade only), 1x Headphone Jack |
| Oke VESA | 100mm x 100mm |
| Titunse pulọọgi | -5 si 15 iwọn |
| Oju Itọju Awọn ẹya ara ẹrọ | Kò ní fẹ́lẹ́fẹ́lẹ́, ìmọ́lẹ̀ búlúù kékeré |
Atilẹyin ọja ati Support
KTC provides a 3-year warranty and a 12-month exchange service for this product. For any questions or issues, please contact customer support.
- Foonu: 050-3606-8990
- Imeeli: support@ktcplay.com
Image: Information regarding KTC's 3-year warranty and contact details for customer support.
Image: Step-by-step guide on how to contact customer support via Amazon.
