Trolinktek TAB0E 2-in-1 Wireless CarPlay & Android Auto Adapter User Manual

1. Ifihan

The Trolinktek TAB0E 2-in-1 Wireless CarPlay & Android Auto Adapter is designed to convert your vehicle's existing wired CarPlay or Android Auto system into a wireless connection. This device allows for seamless integration of your smartphone's features onto your car's infotainment display without the need for cables, enhancing convenience and reducing clutter.

2. Ohun ti o wa ninu Apoti

Nigbati o ba ṣii package, o yẹ ki o wa awọn nkan wọnyi:

• 1 x Wireless CarPlay & Android Auto Adapter (Trolinktek TAB0E)
• 1 x USB-A to USB-C Adapter Cable
• 1 x Itọsọna olumulo

Figure 1: Package Contents. This image displays the wireless adapter, a USB-C adapter cable, and the user manual, which are included in the product box.

3. Eto ati fifi sori

Follow these steps to connect your Trolinktek TAB0E adapter to your vehicle's infotainment system:

1. Ṣe idanimọ Ibudo USB: Locate the data USB port in your car's infotainment system. This is typically the port used for wired CarPlay or Android Auto. Note: Do not use a charging-only USB port.
2. So Adapter:
   • If your car has a standard USB-A port, plug the wireless adapter directly into it.
   • If your car has a USB-C port, use the provided USB-A to USB-C adapter cable to connect the wireless adapter.
3. Agbara Tan: Once plugged in, the adapter will power on, indicated by an LED light.
4. Bata nipasẹ Bluetooth:
   • On your smartphone, go to Eto > Bluetooth.
   • Wa fun available devices and select the adapter (e.g., "WirelessDongle-XXXX").
   • Confirm the pairing request on both your phone and the car's display if prompted.
5. Asopọmọra Aifọwọyi: After successful Bluetooth pairing, your phone will automatically connect to the adapter via Wi-Fi, initiating either CarPlay or Android Auto on your car's display.

Figure 2: Adapter plugged into a car's USB port. The compact design ensures a secure and tidy connection.

Figure 3: Plug & Play setup. The adapter supports both USB-A and USB-C ports for easy installation.

Figure 4: Wireless convenience. The adapter eliminates cable clutter for a cleaner car interior.

4. Awọn ilana Iṣiṣẹ

Once connected, the adapter enables wireless access to your smartphone's features through your car's infotainment system. You can interact with CarPlay or Android Auto using your car's original controls.

• Isopọpọ aladaaṣe: After the initial setup, the adapter will automatically reconnect to your phone within seconds each time you start your car.
• Dual Phone Support: The adapter can store pairing information for two phones and will automatically switch to the available phone if one is not present.
• Awọn ọna Iṣakoso: Utilize your car's existing controls for navigation, music, and calls:
  • Iṣakoso Fọwọkan: Interact directly with the car's touchscreen display.
  • Awọn idari Kẹkẹ idari: Use buttons on your steering wheel to manage audio, calls, and navigation.
  • OEM Knob/Controller: Operate through your car's factory-installed rotary knob or central controller.
  • Oluranlọwọ ohun: Activate Siri or Google Assistant for hands-free commands (e.g., "Hey Siri," "OK Google") to play music, get directions, or make calls.

Figure 5: Original Control Integration. The adapter supports touch, wheel, and OEM knob controls, as well as voice commands.

Figure 6: Intelligent Voice Assistant. Use voice commands for safe, hands-free operation of your car's infotainment system.

5. Ibamu

The Trolinktek TAB0E adapter offers broad compatibility:

• Ibamu Ọkọ: Compatible with over 1,000 vehicle models that have factory-installed wired CarPlay (800+ models) or wired Android Auto (500+ models) after 2015.
• Ibamu Foonuiyara:
  • Apple CarPlay: Supports iPhone 6 or later, running iOS 10.0 or above.
  • Android Auto: Supports Android 11.0 or above.
• Awọn akọsilẹ pataki:
  • Ṣe KO support video applications like YouTube or Netflix.
  • Ṣe KO support BMW, Tesla, or Motorcycles.
  • Ṣe KO support cars without OEM wired CarPlay.
  • Lexus models after 2020 are generally not supported.

Figure 7: Wide Compatibility. The adapter supports a broad range of iPhones and Android devices, and many car models. Scan the QR codes to check specific car model compatibility for CarPlay ati Android Auto.

6. Laasigbotitusita

Tí o bá ní ìṣòro, ronú nípa àwọn nǹkan wọ̀nyí:

• Ko si Asopọmọra:
  • Ensure the adapter is plugged into a data USB port, not a charging-only port.
  • Verify your car has factory-installed wired CarPlay or Android Auto.
  • Check your phone's Bluetooth settings to ensure it's paired with the adapter.
  • Tun foonu rẹ ati eto infotainment ọkọ ayọkẹlẹ naa bẹrẹ.
• Ìsopọ̀/Ìdínà Lẹ́sẹ̀kẹsẹ̀:
  • Ensure there are no other Bluetooth devices actively interfering with your phone's connection to the adapter.
  • Check for firmware updates (see "Smart OTA Updates" in Specifications).
  • Ensure your phone's Wi-Fi is enabled, as the adapter uses Wi-Fi for data transfer after Bluetooth pairing.
• Adapter gbigbona: While designed for efficient performance, if the adapter feels excessively hot, ensure it has adequate ventilation and is not obstructed.
• Aibaramu: Refer to the compatibility section. If your car or phone model is explicitly listed as unsupported, the adapter will not function.

7. Awọn pato

Figure 8: Efficient Performance. The upgraded chipset ensures faster connection speeds, stronger signals, and enhanced stability.

8. Atilẹyin ọja ati Support

Trolinktek is committed to providing reliable products and excellent customer service.

• Idaabobo ọja: The adapter comes with a 12-month product protection plan.
• Oluranlowo lati tun nkan se: Lifetime technical support is available 24/7 from our expert support team.
• Awọn imudojuiwọn famuwia: Free remote firmware updates (OTA) are provided to ensure compatibility with future iOS/Android updates and to improve performance.
• Return and Exchange: A 1-year return and exchange warranty service is included, supporting returns if the product is incompatible with your vehicle.

For assistance, please contact Trolinktek customer support.
