Mesqool Digital Alarm Clock CR1008 User Manual

1. Ifihan

O ṣeun fun riraasing the Mesqool Digital Alarm Clock CR1008. This manual provides detailed instructions to help you set up and operate your new alarm clock, ensuring you can utilize all its features effectively. This clock is designed for ease of use and includes features such as a large display, adjustable brightness, a multi-color night light, and convenient charging ports.

2. Key Awọn ẹya ara ẹrọ

• 7.5-inch Large Number Screen: Highly visible time display for easy reading from a distance.
• 5-Level Brightness Dimmer: Adjustable display brightness from very bright to very dim, allowing for comfortable viewing ọjọ tabi oru.
• Imọlẹ Alẹ 7-Awọ: Integrated night light with 7 color options and adjustable brightness, perfect for ambient lighting.
• Awọn ibudo gbigba agbara USB meji: Includes one USB-A and one Type-C port for convenient charging of mobile devices.
• Iwọn didun Itaniji ti o le ṣatunṣe: Alarm volume can be set to low, medium, or high, with a maximum of 80 dB, suitable for heavy sleepers.
• Gradual Alarm Sound: Alarm starts softly and gradually increases in volume to provide a gentle wake-up experience.
• 9-Minute Snooze Function: Large, easy-to-press snooze button for an additional 9 minutes of sleep.
• Àkókò Ìpele 12H/24H: Slider switch to easily select between 12-hour and 24-hour time display formats.
• Batiri Afẹyinti: Requires 2 AAA batteries (not included) to maintain time and alarm settings during a power outage.
• Iṣẹ́ Àkókò Ìfipamọ́ Ọ̀sán (DST): Convenient switch for adjusting to Daylight Saving Time.

3. Eto

3.1 Asopọ agbara

The Mesqool Digital Alarm Clock CR1008 is a plug-in electric alarm clock. For all functions, including time display, alarm, and USB charging, the clock must be connected to a DC wall power outlet using the provided 5V 2A power adapter.

3.2 Batiri Afẹyinti fifi sori

To ensure your time and alarm settings are retained during a power failure, install 2 AAA batteries (not included) into the battery compartment located on the back of the unit. The screen display will not turn on when operating solely on battery backup; batteries are for memory retention only.

Figure 1: Battery backup compartment and power connection. Note: AAA batteries are not included.

3.3 Ibẹrẹ Agbara Lori

Once plugged in, the clock display will illuminate. You may then proceed to set the time and alarm as described in the operating instructions.

4. Awọn ilana Iṣiṣẹ

4.1 Ṣiṣeto Aago naa

1. Tẹ awọn SET Akoko button once. The hour digits will begin to flash.
2. Lo awọn WAKATI button (left button on top) to adjust the hour.
3. Tẹ awọn SET Akoko bọtini lẹẹkansi. Awọn nọmba iṣẹju yoo filasi.
4. Lo awọn ISEJU button (right button on top) to adjust the minutes.
5. Tẹ awọn SET Akoko bọtini kan ni igba kẹta lati jẹrisi ati jade ipo eto akoko.

4.2 12H/24H Time Format Selection

Wa awọn Akoko fọọmu slider switch on the back of the clock. Slide it to select either the 12-hour or 24-hour display format according to your preference.

Figure 2: Switching between 12H and 24H time formats.

4.3 Eto Itaniji

1. Tẹ awọn ṢETO itaniji button once. The alarm hour digits will begin to flash.
2. Lo awọn WAKATI button (left button on top) to adjust the alarm hour.
3. Tẹ awọn ṢETO itaniji button again. The alarm minute digits will flash.
4. Lo awọn ISEJU button (right button on top) to adjust the alarm minutes.
5. Tẹ awọn ṢETO itaniji button a third time to confirm and exit alarm setting mode.
6. To activate or deactivate the alarm, use the IKỌ NIPA / PA switch located on the back of the clock.

4.4 Ṣíṣe àtúnṣe iwọn didun itaniji

On the back of the clock, locate the ORO AGBARA slider. Slide it to select your desired alarm volume: LỌWỌ, MED (Medium), or GIGA. The highest setting provides a loud alarm suitable for heavy sleepers.

Figure 3: Adjustable alarm volume levels.

4.5 Iṣiṣẹ Snooze

Nigbati itaniji ba ndun, tẹ tobi SNOOZE / LIGHT button on the top of the clock to temporarily silence the alarm for 9 minutes. The alarm will sound again after the snooze period. To turn off the alarm completely, press the ÌDÌÍRÌN ÌDÍMI bọtini lori pada.

Figure 4: Utilizing the snooze function for extra rest.

Iṣẹ́ ìmọ́lẹ̀ alẹ́ 4.6

Tap the large SNOOZE / LIGHT button on the top of the clock to cycle through 7 different night light colors. Continue tapping to change colors. To turn off the night light, cycle through all colors until it switches off, or press and hold the button.

Figure 5: The 7-color night light feature.

4.7 Adjusting Display Brightness (Dimmer)

On the back of the clock, locate the DIMMER slider. Slide it to adjust the brightness of the time display from its brightest to its dimmest setting. This allows you to customize the display visibility to your comfort level, especially for nighttime use.

Figure 6: Adjusting the 5-level display dimmer.

4.8 Lilo awọn ibudo gbigba agbara USB

The clock is equipped with a standard USB-A port and a Type-C port on the back. These ports allow you to charge your mobile devices conveniently while the clock is plugged into a wall outlet. This helps reduce the number of power outlets needed in your bedroom.

Figure 7: USB and Type-C charging ports.

4.9 Akoko Ifipamọ Oju-ọjọ (DST)

Wa awọn DST switch on the back of the clock. Slide it to activate or deactivate the Daylight Saving Time adjustment as needed.

5. Itọju

• Ninu: Wipe the clock with a soft, dry cloth. Avoid using abrasive cleaners or solvents.
• Ifihan Olomi: Do not expose the clock to water or other liquids.
• Ibi: Gbe aago sori iduro, dada alapin kuro lati orun taara, awọn orisun ooru, ati ọrinrin pupọ.
• Rirọpo Batiri: Replace AAA backup batteries annually or when the battery indicator suggests low power to ensure continuous memory retention.

6. Laasigbotitusita

• Clock Display is Off: Ensure the power adapter is securely plugged into both the clock and a working wall outlet. If using battery backup, remember the display does not illuminate; batteries only retain settings.
• Itaniji Ko N dun: Check that the ALARM ON/OFF switch on the back is in the 'ON' position. Verify the alarm time is correctly set.
• Awọn ibudo USB Ko Ngba agbara: Confirm the clock is properly plugged into a wall outlet. Ensure your device's charging cable is functional and correctly connected to the USB or Type-C port.
• Display Too Bright/Dim: Adjust the DIMMER slider on the back of the clock to your preferred brightness level.
• Night Light Not Changing Colors: Tap the SNOOZE/LIGHT button repeatedly to cycle through all available colors. If it remains stuck, try unplugging and re-plugging the clock to reset it.

7. Awọn pato

8. Atilẹyin ọja ati Support

The Mesqool Digital Alarm Clock CR1008 comes with a one-year limited warranty. Additionally, Mesqool offers a 30-day money-back guarantee and 24-hour response support. For any inquiries or assistance, please contact support@mesqool.com.
