E-flite Carbon-Z Cessna 150 2.1M BNF Basic RC Airplane Instruction Manual

1. Ọja Ipariview

The E-flite Carbon-Z Cessna 150 2.1M BNF Basic is a large-scale remote control aircraft designed for sport flying. This model offers a wide flight envelope, suitable for various flying styles. It incorporates scale details and features for an enhanced experience.

Awọn ẹya pataki:

• Large sport-scale model suitable for diverse flight maneuvers.
• Wide flight envelope, accommodating both gentle and aggressive flying.
• Scale details including LED lights, functional flaps, and wheel pants.
• Designed for field assembly without requiring tools.
• Innovative hands-free servo connection system for simplified setup.

olusin 1.1: Iwaju view of the E-flite Carbon-Z Cessna 150 2.1M RC Airplane.

2. Alaye Aabo

IKILO: Ka gbogbo itọnisọna itọnisọna lati di faramọ pẹlu awọn ẹya ara ẹrọ ti ọja ṣaaju ṣiṣe. Ikuna lati ṣiṣẹ ọja daradara le ja si ibajẹ ọja, ohun-ini ti ara ẹni ati fa ipalara nla. Eleyi jẹ a fafa ifisere ọja. O gbọdọ ṣiṣẹ pẹlu iṣọra ati oye ti o wọpọ ati nilo diẹ ninu agbara ẹrọ ipilẹ. Ikuna lati ṣiṣẹ ọja yi ni ọna ailewu ati lodidi le ja si ipalara tabi ibajẹ ọja tabi ohun-ini miiran. Ọja yii kii ṣe ipinnu fun lilo nipasẹ awọn ọmọde laisi abojuto agbalagba taara. Ma ṣe lo pẹlu awọn paati ti ko ni ibamu tabi paarọ ọja yii ni eyikeyi ọna ita awọn itọnisọna ti a pese nipasẹ Horizon Hobby, LLC. Iwe afọwọkọ yii ni awọn ilana fun aabo, isẹ ati itọju. O ṣe pataki lati ka ati tẹle gbogbo awọn itọnisọna ati awọn ikilọ ninu iwe afọwọyi, ṣaaju iṣakojọpọ, iṣeto tabi lilo, lati le ṣiṣẹ ni deede ati yago fun ibajẹ tabi ipalara nla.

3. Ohun ti o wa ninu Apoti

• Carbon-Z Cessna 150 BNF Basic RC Airplane

Note: Additional components such as a compatible Spektrum DSMX/DSM2 transmitter, flight battery, and charger are required and sold separately.

4. Eto ati Apejọ

4.1 Wing Assembly

1. Carefully slide each wing panel onto the wing tube until it is fully seated against the fuselage.
2. Ensure the hands-free servo connections engage properly.
3. Secure each wing panel using the provided fasteners or pins, as indicated in the manual.

Figure 4.1: Detail of component assembly, showing a pin being inserted.

4.2 Landing Gear Installation

Attach the main landing gear and tail wheel assembly according to the diagrams. Ensure all connections are secure. The model features wheel pants for scale appearance.

4.3 Servo Connections

The Carbon-Z Cessna 150 utilizes an innovative hands-free servo connection system. When assembling the wings, ensure the servo connectors align and engage automatically. Verify all control surfaces move freely and correctly after assembly.

Figure 4.2: Detail of the hands-free servo connection system.

4.4 Battery Installation and Binding

1. Install the recommended flight battery (sold separately) into the designated battery compartment. Secure it to prevent movement during flight.
2. Follow the instructions for your Spektrum DSMX/DSM2 compatible transmitter to bind it with the aircraft's receiver. Refer to your transmitter's manual for specific binding procedures.
3. After binding, perform a control surface test to ensure all controls (ailerons, elevator, rudder, throttle) respond correctly to transmitter inputs.

5. Awọn ilana Iṣiṣẹ

5.1 Pre-Flight sọwedowo

• Rí i dájú pé batiri ọkọ̀ òfurufú náà ti gba agbára tán pátápátá, ó sì wà ní ààbò.
• Verify all control surfaces move freely and in the correct direction relative to transmitter inputs.
• Check propeller for any damage or looseness.
• Confirm the transmitter battery is adequately charged.
• Perform a range check of your radio system before the first flight of the day.

5.2 Gbigba kuro

Place the aircraft on a smooth surface facing into the wind. Gradually advance the throttle. Apply slight up-elevator as speed increases to lift off. Maintain a steady climb rate.

5.3 Ofurufu

The Carbon-Z Cessna 150 is designed for stable flight characteristics. Use the ailerons for roll control, elevator for pitch, and rudder for yaw. Adjust throttle to control speed. Utilize flaps for slower flight and improved lift during takeoff and landing, if desired.

Figure 5.1: The Carbon-Z Cessna 150 in stable flight.

5.4 ibalẹ

Approach the landing strip into the wind. Reduce throttle and gradually deploy flaps if using them. Maintain sufficient airspeed for control. Flare gently by applying up-elevator just before touchdown to achieve a smooth landing.

6. Itọju

6.1 Post-Flight Inspection

• Inspect the airframe for any damage, cracks, or loose components.
• Check all control linkages and hinges for wear or looseness.
• Examine the propeller and spinner for damage. Replace if necessary.
• Ensure landing gear is secure and undamaged.

6.2 Ninu ati Ibi ipamọ

Clean the aircraft with a soft, damp cloth. Avoid using harsh chemicals. Store the model in a cool, dry place, away from direct sunlight and extreme temperatures, to preserve its materials and electronics.

7. Laasigbotitusita

8. Awọn pato

Figure 8.1: The Carbon-Z Cessna 150 demonstrating its substantial size.

9. atilẹyin ọja Information

This product is covered by a limited warranty provided by Horizon Hobby, LLC. For detailed warranty terms and conditions, please refer to the official Horizon Hobby website or contact their customer support. Proof of purchase may be required for warranty claims.

10. Onibara Support

For technical assistance, spare parts, or further information regarding your E-flite Carbon-Z Cessna 150, please visit the official E-flite or Horizon Hobby website. You can also contact their customer service department directly for support.

E-flite Store: Visit the E-flite Store on Amazon
