Oasser P2A Portable Tyre Inflator User Manual

1. Ifihan

Thank you for choosing the Oasser P2A Portable Tyre Inflator. This cordless air compressor is designed for convenient and efficient inflation of tyres for cars, motorcycles, and bicycles, as well as other inflatable items. Featuring a digital pressure gauge and a 2000mAh lithium battery, it provides reliable performance for your inflation needs.

Nọmba 1.1: The Oasser P2A Portable Tyre Inflator shown with its complete set of accessories, including various nozzles, charging cable, and storage bag.

2. Alaye Aabo

Please read all safety warnings and instructions carefully before using this product to avoid electric shock, fire, and serious injury.

• Keep the inflator away from children.
• Má ṣe lo inflator náà ní ipò òjò tàbí nítòsí àwọn omi tàbí gáàsì tó lè jóná.
• Ensure the correct pressure setting for the item being inflated to prevent over-inflation and potential damage or injury. Refer to the item's manufacturer specifications for recommended pressure.
• Ma ṣe lọ kuro ni inflator laini abojuto lakoko ti o n ṣiṣẹ.
• Jẹ́ kí inflator náà tutù lẹ́yìn lílo rẹ̀ fún ìgbà pípẹ́ kí ó má ​​baà gbóná jù.
• Use only the provided charging cable and a compatible USB power source for charging.
• Store the inflator in a dry, cool place when not in use.

3. Ọja irinše ati Awọn ẹya ara ẹrọ

The Oasser P2A inflator comes with several components designed for versatile use.

Nọmba 3.1: Key features of the Oasser P2A inflator, highlighting the LED light, digital LCD display, and the integrated 2000mAh lithium battery.

• Ẹka akọkọ: Portable air compressor with integrated digital display and controls.
• Batiri litiumu 2000mAh: Provides cordless operation.
• Ifihan LCD Backlit Digital: Shows current and target pressure clearly.
• Imọlẹ LED: Fun itanna ni awọn ipo ina kekere.
• Awọn okun Atẹgun: Includes both a short and a long air hose for different applications.
• Nozzle Adapters:
  • Adapter Valve Adaṣe
  • Air Nozzle (for inflatables)
  • Bọọlu abẹrẹ
• Okun Ngba agbara USB: Fun gbigba agbara ẹrọ naa.
• Apo Ibi ipamọ: For convenient storage and transport of the inflator and accessories.

Nọmba 3.2: All accessories included with the Oasser P2A Tyre Inflator, laid out for clear identification.

4. Eto ati gbigba agbara

4.1 Ni ibẹrẹ idiyele

Before first use, fully charge the Oasser P2A inflator. It is recommended to charge the battery to full capacity within 3 days after every use to maintain battery health.

1. Connect the provided USB charging cable to the charging port on the inflator.
2. Connect the other end of the USB cable to a compatible USB power adapter (e.g., phone charger, computer USB port).
3. The charging indicator on the inflator will show the charging status. Charge until the battery indicator shows full.

Nọmba 4.1: The inflator connected to a USB power source for charging, illustrating its home charging capability.

4.2 Síso Póìpù Afẹ́fẹ́ Mọ́

Select the appropriate air hose (short or long) and screw it firmly onto the inflator's air outlet. Ensure a tight seal to prevent air leakage during inflation.

5. Awọn ilana Iṣiṣẹ

5.1 Awọn Igbesẹ Afikun Ipilẹ

1. Tan-an: Press the middle button on the unit to power it on. The digital display will illuminate.
2. So Air Hose: Screw the air hose onto the tyre valve. For different items, attach the appropriate nozzle adapter (e.g., Presta valve adapter for bicycles, ball needle for sports balls).
3. Ṣeto Ipa Ti o fẹ: Use the "+" and "-" buttons to adjust the target pressure. The display will flash four times to confirm the setting.
4. Ibẹrẹ Iṣeduro: Press the start button (trigger) to begin inflation. The inflator will automatically stop when the preset pressure is reached.
5. Ge asopọ: Once inflation is complete, disconnect the air hose from the valve.

Nọmba 5.1: Visual guide for the inflation process, from powering on to automatic shut-off.

5.2 Digital Display and LED Light

The digital backlit LCD display provides clear readings of pressure. The integrated LED light can be activated to assist with inflation in dark environments, such as at night or in dimly lit garages.

Nọmba 5.2: The clear digital display for precise pressure monitoring.

Nọmba 5.3: The LED light in operation, providing visibility for nighttime use.

5.3 Inflation Capacity

The 2000mAh lithium battery provides sufficient power for multiple inflations on a single charge. For example, it can inflate approximately:

• Up to 4 car tyres (size 185/70R14)
• Up to 10 motorcycle tyres
• Up to 25 bicycle tyres

Nọmba 5.4: Battery capacity and estimated inflation counts for various vehicle types.

5.4 Fast Inflation

The Oasser P2A is equipped with a powerful engine capable of fast inflation. For instance, it can inflate a 165/70 R14 car tyre from 15 PSI to 35 PSI in approximately 3 minutes.

Nọmba 5.5: The inflator in action, demonstrating its fast inflation capability and key operational features.

6. Itọju

• Ninu: Mu ese ita ti inflator pẹlu asọ, damp asọ. Maṣe lo awọn kẹmika ti o lewu tabi awọn afọmọ abrasive.
• Ibi ipamọ: Tọ́jú ẹ̀rọ inflation àti àwọn ohun èlò mìíràn tó wà nínú rẹ̀ sínú àpò ìtọ́jú tí a pèsè sí ibi gbígbẹ tí ó tutù, tí kò sí ìmọ́lẹ̀ oòrùn tààrà àti ooru tó le koko.
• Itọju Batiri: As noted in the operating instructions, charge the battery fully within 3 days after each use to prolong its lifespan. Avoid completely draining the battery before recharging.
• Ayẹwo okun ati Nozzle: Regularly check the air hoses and nozzle adapters for any signs of wear, cracks, or damage. Replace if necessary to ensure proper function and prevent air leaks.

7. Laasigbotitusita

8. Awọn pato

9. Atilẹyin ọja ati Support

Oasser products are designed for reliability and performance. For warranty information or technical support, please refer to the contact details provided in the original product packaging or visit the official Oasser webojula. Jọwọ ṣe idaduro ẹri rira rẹ fun awọn iṣeduro atilẹyin ọja.

Akiyesi: Some customer reviews mention a positive experience with Oasser's support regarding product issues, indicating a willingness to assist with replacements or solutions.
