IKEA NOLLATTA Digital Alarm Clock - User Manual

1. Ifihan

Thank you for choosing the IKEA NOLLATTA Digital Alarm Clock. This manual provides essential information for the safe and efficient use of your new alarm clock. Please read it thoroughly before use and keep it for future reference.

The IKEA NOLLATTA is a modern digital alarm clock featuring a clear LED display, adjustable brightness, and a compact design suitable for various spaces. It operates via a USB power cable and includes a battery backup for time memory.

2. Alaye Aabo

• Ensure the product is connected to a compatible USB power source (5V/1A adapter, not included).
• Do not expose the clock to water or excessive humidity.
• Keep the clock away from direct sunlight and heat sources.
• Only use the specified CR2032 3V lithium battery for time memory. Incorrect battery type may cause damage.
• Do not attempt to disassemble or repair the clock yourself. Contact qualified service personnel for assistance.
• Keep batteries out of reach of children. Swallowing batteries can be fatal.

3. Package Awọn akoonu

Jẹrisi pe gbogbo awọn ohun kan wa ninu package:

• IKEA NOLLATTA Digital Alarm Clock (Main Unit)
• USB Power Cable (1.5m)
• Ojú-iṣẹ iduro
• Itọsọna olumulo

Note: A CR2032 3V lithium battery is required for time memory backup but is sold separately and not included in the package. A 5V/1A USB power adapter is also required and sold separately.

4. Ọja Ipariview

The IKEA NOLLATTA features a minimalist design with a clear LED display. The main unit includes control buttons on the back for setting time and alarms, and a light sensor for automatic brightness adjustment.

Figure 1: IKEA NOLLATTA Digital Alarm Clock in a bedroom setting.

olusin 2: Ẹyìn view of the clock, highlighting the control buttons, USB port, and battery compartment.

Control Buttons (Rear of Clock):

• Bọtini MODE: Used to switch between time, date, and temperature display modes, and to enter setting modes.
• Bọtini UP: Used to increase values during setting, or to adjust brightness.
• Bọtini isalẹ: Used to decrease values during setting, or to adjust brightness.

Awọn ẹya miiran:

• Sensọ Imọlẹ: Automatically adjusts display brightness based on ambient light.
• Ibudo Agbara USB: Connects the clock to a power source using the included USB cable.
• Abala Batiri: Holds a CR2032 3V lithium battery for time memory backup.

5. Eto

5.1. Asopọ agbara

1. Insert the small end of the included USB power cable into the USB power port on the back of the clock.
2. Connect the other end of the USB cable to a 5V/1A USB power adapter (not included) and plug it into a wall outlet. The display will light up.

5.2. Installing Time Memory Battery (CR2032, sold separately)

The CR2032 battery provides backup power to retain time settings in case of a power outage or when the USB cable is disconnected. The display will not be active on battery power alone, but the internal clock and alarm settings will be preserved.

1. Wa yara batiri ni ẹhin aago naa.
2. Ṣii ideri iyẹwu batiri naa.
3. Insert one CR2032 3V lithium battery, ensuring correct polarity (+/-).
4. Pa ideri batiri naa ni aabo.

5.3. Ifiweranṣẹ

The IKEA NOLLATTA can be placed on a flat surface using the included desktop stand or mounted on a wall.

• Ibi tabili: Attach the desktop stand to the bottom of the clock. Place the clock on a stable, flat surface.
• Iṣagbede ogiri: The clock has keyhole slots on the back for wall mounting. Use appropriate screws and wall plugs (not included) for your wall type. Ensure the clock is securely mounted before releasing o.

6. Awọn ilana Iṣiṣẹ

6.1. Eto Aago ati Ọjọ

1. Tẹ mọlẹ MODE button for 3 seconds to enter time setting mode. The hour digits will start blinking.
2. Lo awọn UP ati SILE awọn bọtini lati ṣatunṣe awọn wakati.
3. Tẹ MODE lẹ́ẹ̀kan sí i láti gbéra sí ìṣètò ìṣẹ́jú. Lo UP ati SILE lati ṣatunṣe awọn iṣẹju.
4. Tesiwaju titẹ MODE to cycle through setting the year, month, and day, adjusting each with the UP ati SILE awọn bọtini.
5. Lẹ́yìn tí o bá ti ṣètò ọjọ́ náà, tẹ MODE lati jade kuro ni ipo eto.

6.2. 12/24-Hour Format Selection

Ni ipo ifihan akoko deede, tẹ bọtini naa UP bọtini lati yi laarin 12-wakati ati 24-wakati ọna kika.

6.3. Eto Itaniji

The alarm function works even when the display is turned off.

1. Tẹ awọn MODE button repeatedly until "AL" appears on the display, indicating alarm mode.
2. Tẹ mọlẹ MODE button for 3 seconds. The alarm hour digits will start blinking.
3. Lo awọn UP ati SILE awọn bọtini lati ṣeto wakati itaniji ti o fẹ.
4. Tẹ MODE lẹ́ẹ̀kan sí i láti lọ sí ètò ìṣẹ́jú itaniji. Lo UP ati SILE lati ṣeto awọn iṣẹju.
5. Tẹ MODE lati jẹrisi ati jade kuro ni eto itaniji.
6. To activate/deactivate the alarm, in alarm mode ("AL" displayed), press the UP bọtini. Aami itaniji yoo han/farahan loju iboju.
7. When the alarm sounds, press any button to snooze. To turn off the alarm, press and hold the MODE bọtini.

6.4. Tolesese Imọlẹ

The clock offers 3 levels of brightness (High, Medium, Low) and an automatic adjustment mode, as well as an OFF setting for the display.

• Ni ipo ifihan akoko deede, tẹ bọtini naa SILE button repeatedly to cycle through brightness levels: High → Medium → Low → OFF.
• The clock also features an automatic brightness adjustment function via its built-in light sensor.

6.5. Display Rotation Mode

The clock can cycle through displaying time, date, and temperature.

1. Ni ipo ifihan akoko deede, tẹ bọtini naa MODE button briefly to switch between Time, Date, and Temperature displays.
2. To activate automatic cycling through Time, Date, and Temperature, press and hold the MODE button until the display starts rotating.
3. To stop automatic cycling and return to a static display, press the MODE bọtini ni soki lẹẹkansi.

7. Itọju

7.1. Ninu

Wipe the clock surface with a soft, dry cloth. Do not use abrasive cleaners or solvents, as they may damage the finish.

7.2. Batiri Rirọpo

If the time memory function is no longer working during power disconnection, replace the CR2032 3V lithium battery in the battery compartment (refer to section 5.2).

8. Laasigbotitusita

9. Awọn pato

• Awoṣe: NOLLATTA (704.993.50)
• Àwọ̀: Funfun
• Awọn iwọn (isunmọ): Length: 21.5 cm, Height: 8.5 cm, Depth: 4 cm
• Awọn ohun elo: Clock face: Polystyrene plastic; Back cover/feet: ABS plastic
• Orisun Agbara: USB (5V/1A adapter required, not included)
• Batiri Afẹyinti: 1 x CR2032 3V Lithium Battery (sold separately) for time memory
• Gigun USB: 1.5m USB cable included
• Iru ifihan: LED Digital
• Awọn ẹya: 3-level dimming, 12/24-hour format, alarm function, automatic brightness adjustment

10. Atilẹyin ọja ati Support

For information regarding warranty, returns, or technical support, please refer to the purchase documentation or contact your IKEA retailer directly. Keep your proof of purchase for any warranty claims.
