1. Ifihan
This manual provides detailed instructions for the installation, operation, and maintenance of your ieGeek K301 Car Radio. Please read this manual thoroughly before using the product to ensure proper function and safety.
Key Awọn ẹya ara ẹrọ
- FM/AM Stereo Radio with RDS: Supports reception of FM/AM stereo radio and can store up to 30 radio stations. RDS functions provide automatic traffic announcements for enhanced road safety.
- Bluetooth 5.0 Asopọmọra: Offers stable and reliable Bluetooth connection for hands-free calls and music streaming from iOS/Android devices.
- Sisisẹsẹhin Media: Supports MP3/WMA/WAV audio formats via USB drive and micro SD card.
- AUX-IN Input: Front-facing AUX IN port for connecting external audio devices.
- Ngba agbara USB: Independent 5V-2A USB charging interface for quick mobile phone charging.
- Ifihan aago: Independent clock display window for easy time viewing.
- Iranti-Agbara: Retains settings and last played station/track after power-off.
- Ohun Imudara: Integrated 4x55W amplification for clear audio. Features Extra Bass and customizable sound profiles.
2. Package Awọn akoonu
Jẹrisi pe gbogbo awọn ohun kan wa ninu package:
- 1x ieGeek K301 Car Radio
- 1x Itọsọna olumulo
- 1x Isakoṣo latọna jijin
- 2x Awọn okun agbara
- 2x Removal Keys
3. fifi sori
Proper installation is crucial for optimal performance. If you are unsure about any steps, consult a professional car audio installer.
3.1 Wiring aworan atọka
Refer to the following diagram for correct wiring connections. Ensure all connections are secure to prevent malfunctions.
- Asopọ agbara: Connect the yellow wire directly to the car battery's positive terminal (constant 12V) to ensure memory retention for settings and radio stations. The red wire should connect to the ignition switch (switched 12V). The black wire is for ground.
- Awọn isopọ Agbọrọsọ: Connect the speaker wires according to the diagram, ensuring correct polarity for each speaker.
- Asopọmọra Antenna: Connect your car's antenna cable to the radio. An adapter may be required for certain vehicle models.
3.2 Iṣagbesori Unit
- Insert the metal mounting sleeve into the dashboard opening. Bend the tabs to secure it.
- Connect all necessary wiring harnesses to the rear of the car radio.
- Carefully slide the car radio into the mounting sleeve until it clicks into place.
- Use the provided removal keys to extract the unit if needed for future maintenance or replacement.
4. Awọn ilana Iṣiṣẹ
4.1 Ipilẹ idari
- Power/Volume Knob (VOL): Press to turn on/off. Rotate to adjust volume.
- Bọtini MODE: Press to cycle through available modes (FM, AM, USB, SD, AUX, Bluetooth).
- BAND/AMS Button: In radio mode, press to switch between FM1/FM2/FM3/AM1/AM2 bands. Long press to automatically scan and store stations.
- SEL/RDS Knob: Press to access audio settings (Bass, Treble, Balance, Fader, EQ). Rotate to adjust values. Long press for RDS functions (if available).
- Awọn bọtini Tito tẹlẹ (1-6): In radio mode, short press to select a stored station. Long press to store the current station.
- Forward/Backward Buttons (◀◀/▶▶): In media playback, short press for previous/next track. Long press for fast rewind/forward. In radio mode, short press for manual tuning, long press for auto-seek.
4.2 Radio Operation (FM/AM/RDS)
- Tẹ awọn MODE button until "FM" or "AM" is displayed.
- Tẹ BAND/AMS to select the desired frequency band (FM1, FM2, FM3, AM1, AM2).
- Lo awọn ◀◀/▶▶ buttons to tune to a station. Long press for automatic station seeking.
- To store a station, tune to the desired frequency, then long press one of the Àwọn bọ́tìnì tí a ti ṣètò tẹ́lẹ̀ (1-6) titi ifihan yoo fi tan.
- Iṣẹ́ RDS: If available in your region, the radio will display station information. Long press the SEL/RDS knob to activate/deactivate RDS features like traffic announcements.
4.3 USB / SD Kaadi Sisisẹsẹhin
- Insert a USB drive into the USB port or an SD card into the SD card slot. The unit will automatically switch to USB/SD mode and begin playback.
- Tí kò bá yípadà láìfọwọ́sí, tẹ MODE button to select "USB" or "SD".
- Lo awọn ◀◀/▶▶ awọn bọtini lati lilö kiri awọn orin.
- Awọn 1/▶▶ button can be used for play/pause.
- Awọn 3 / RPT button can be used for repeat functions.
4.4 Ìsopọ̀ AUX-IN
- Connect your external audio device (e.g., smartphone, MP3 player) to the front AX IN ibudo lilo a 3.5mm iwe USB.
- Tẹ awọn MODE bọtini titi "AUX" yoo han.
- Ṣakoso ṣiṣiṣẹsẹhin ati iwọn didun lati ẹrọ ita rẹ.
4.5 Bluetooth Isẹ
- Pipọpọ:
- Tẹ awọn MODE button until "BT" (Bluetooth) is displayed.
- Lori ẹrọ alagbeka rẹ, mu Bluetooth ṣiṣẹ ki o wa awọn ẹrọ to wa.
- Select "K301" from the list. If prompted for a password, enter "0000".
- Once paired, the display will show "BT ON" or a similar confirmation.
- Ṣiṣanwọle ohun ohun Bluetooth:
- After successful pairing, open your music player on your mobile device.
- Audio will stream through the car radio. Use the ◀◀/▶▶ buttons on the radio to control tracks.
- Npe ni Ọwọ:
- When a call comes in, the radio will display the caller's number (if available).
- Tẹ awọn VOL knob to answer a call. Press again to end a call.
- Lo gbohungbohun ti a ṣe sinu rẹ fun ibaraẹnisọrọ.
4.6 USB Ngba agbara
The dedicated USB port provides 5V-2A output for charging mobile devices. Simply connect your device using a compatible USB cable.
4.7 Clock Display and Setting
The unit features an independent clock display. To set the time:
- With the unit powered on, long press the DISP button (if available, or a combination with MODE/VOL). If no specific DISP button, the clock is usually set via the MODE button or a long press on the VOL knob in some modes.
- Lo awọn ◀◀/▶▶ awọn bọtini tabi VOL knob to adjust hours and minutes.
- Tẹ awọn VOL knob again to confirm.
4.8 Iṣakoso latọna jijin
The included remote control allows for convenient operation of the car radio from a distance. Point the remote control towards the unit's IR receiver. Functions include power, mode selection, volume adjustment, track/station navigation, and preset selection.
5. Itọju
- Ninu: Lo aṣọ rírọrùn tí ó gbẹ láti nu iwájú pánẹ́ẹ̀lì náà. Má ṣe lo àwọn ohun ìfọmọ́ tàbí àwọn ohun èlò ìfọ́mọ́.
- Rirọpo Fuse: If the unit does not power on, check the 15A fuse located at the rear of the unit. Replace it with a fuse of the same rating if blown.
6. Laasigbotitusita
| Isoro | Owun to le Fa | Ojutu |
|---|---|---|
| Ẹka ko ni agbara. | Blown fuse; incorrect power wiring. | Check and replace the 15A fuse. Verify power cable connections (red, yellow, black). |
| Settings/stations are lost after turning off the car. | Yellow (memory) wire not connected to constant 12V. | Ensure the yellow power cable is connected directly to a constant 12V source from the car battery. |
| Gbigba redio ti ko dara. | Antenna not connected properly; weak signal area. | Check antenna connection. Ensure an antenna adapter is used if necessary. Try a different location. |
| Awọn oran asopọ Bluetooth. | Device not in pairing mode; incorrect pairing process. | Ensure the radio is in BT mode. Re-enable Bluetooth on your mobile device and re-attempt pairing. |
| Poor microphone quality during calls. | Background noise (e.g., AC fan); microphone interference. | Reduce background noise. Avoid placing mobile phone too close to the unit during calls. |
| Screen difficult to read in bright sunlight. | High ambient light; no contrast adjustment. | This is a characteristic of the display type. No user adjustment for contrast is available. |
| Caller ID shows number, not name. | Unit limitation. | The unit displays the caller's number only. Name display is not supported. |
7. Awọn pato
| Ẹya ara ẹrọ | Ẹ̀kúnrẹ́rẹ́ |
|---|---|
| Awọn ọna Voltage | 9-30 V |
| Fiusi | 15A |
| Impedance Agbọrọsọ | 4Ω |
| O pọju o wu Power | 60 W (4x15W RMS) |
| Iwọn Igbohunsafẹfẹ FM | 87.5 - 107.9 MHz |
| AM Igbohunsafẹfẹ Range | 522 - 1620 MHz |
| Asopọmọra | Bluetooth 5.0, USB Type A, AUX-IN, Micro SD |
| Lapapọ Awọn ibudo USB | 2 (1x Data/Media, 1x Charging) |
| Compatible Audio Formats | MP3, WMA, WAV |
| Awọn ẹrọ ibaramu | Speakers, Android, iOS devices |
| Ipo Ijade Ohun | Sitẹrio |
| Kakiri Ohun ikanni iṣeto ni | 4.0 |
| Iwọn Nkan | 772 giramu |
| Nọmba awoṣe | K301 |
| ASIN | B0912HPZT2 |
8. Atilẹyin ọja ati Support
For warranty information and technical support, please refer to the documentation provided with your purchase or visit the official ieGeek webojula. Jeki ẹri rira rẹ fun awọn iṣeduro atilẹyin ọja.
For further assistance, you may contact ieGeek customer service through their official channels. The brand store can be found Nibi.
