Inateck Redcomets U27 PCIe USB 3.2 Gen 2x2 Card

1. Ifihan

The Inateck Redcomets U27 is a high-performance PCIe expansion card designed to add a single USB 3.2 Gen 2x2 Type-C port to your computer. This card provides an exclusive 20 Gbps bandwidth, significantly enhancing data transfer speeds for compatible devices. It is engineered for reliability and ease of use, drawing power directly from the PCIe slot without requiring an external power supply.

Image 1.1: The Inateck Redcomets U27 PCIe USB 3.2 Gen 2x2 Card, highlighting its 20Gbps bandwidth and self-powered design.

Awọn ẹya pataki:

• High-speed Transmission: Dedicated USB Type-C port with 20 Gbps bandwidth.
• Ibamu gbooro: Supports Windows 8/10/11 (32/64 bit) and Linux operating systems.
• Dual Brackets: Includes both standard and low-profile brackets for versatile installation in various PC cases.
• Imudara Aabo: Features ESD protection to prevent short circuits and over-current protection for connected devices.
• No External Power: Draws all necessary power directly from the PCIe slot.

2. Eto ati fifi sori

Follow these steps to properly install your Inateck Redcomets U27 PCIe USB 3.2 Gen 2x2 Card into your computer system.

2.1 Package Awọn akoonu

Ṣaaju fifi sori ẹrọ, rii daju pe gbogbo awọn paati wa ninu package:

Image 2.1: The package includes the Inateck Redcomets U27 PCIe card, a standard bracket, a low-profile bracket, mounting screws, a screwdriver, and an installation guide.

2.2 System Awọn ibeere

• Available PCIe 2.0, 3.0, or 4.0 slot (x4, x8, or x16 recommended for optimal performance).
• Operating System: Windows 8, Windows 10, Windows 11 (32/64 bit), or Linux.
• Akiyesi: This card is not compatible with Windows 7 or macOS.

Image 2.2: Visual representation of compatible operating systems, including Windows 8, 10, 11, and Linux, with a note on incompatibility with Windows 7 and macOS.

2.3 Awọn Igbesẹ Fifi sori ẹrọ Ohun elo

1. Paa ati Ge asopọ: Completely shut down your computer and unplug the power cord from the wall outlet.
2. Ẹran Ṣii: Yọ ẹgbẹ ẹgbẹ ti ọran kọnputa rẹ lati wọle si modaboudu.
3. Wa PCIe Iho: Identify an available PCIe x4, x8, or x16 slot on your motherboard. For maximum performance, a PCIe 3.0 or 4.0 x16 slot is recommended.

Aworan 2.3: alaye view of a PCIe slot, indicating support for PCIe 2.0, 3.0, and 4.0, and compatibility with x4, x8, and x16 slots.
4. Yọ Ideri Iho kuro: Yọ ideri irin kuro ni ẹhin apoti kọmputa rẹ ti o baamu si iho PCIe ti a yan.
5. Install Card: Carefully align the Inateck Redcomets U27 card with the PCIe slot and press it firmly until it is securely seated. Ensure the card's bracket aligns with the opening in the case.


Image 2.4: The Inateck Redcomets U27 PCIe card correctly installed in a computer's PCIe slot, demonstrating that no additional power cables are required.

6. Kaadi to ni aabo: Use the provided screw to secure the card's bracket to the computer case.
7. Ọran pipade: Replace the computer's side panel and reconnect the power cord.
8. Agbara Tan: Turn on your computer. The operating system should automatically detect and install the necessary drivers.

2.4 Bracket Replacement (Optional)

If your computer case requires a low-profile bracket, you can replace the pre-installed standard bracket:

1. Carefully unscrew the two small screws holding the standard bracket to the PCIe card.
2. Remove the standard bracket.
3. Sopọ-kekere Profile bracket with the screw holes on the card and secure it with the screws.

Image 2.5: The Inateck Redcomets U27 PCIe card is supplied with both a full-profile and a low-profile bracket to accommodate different computer case sizes.

3. Awọn ilana Iṣiṣẹ

Once the Inateck Redcomets U27 card is installed and your computer has booted, the USB 3.2 Gen 2x2 Type-C port is ready for use.

3.1 Awọn ẹrọ Nsopọ

Connect your USB 3.2 Gen 2x2 compatible devices (e.g., external SSDs, high-speed storage devices) to the Type-C port on the card. Ensure you use a high-quality USB-C to USB-C cable that supports 20 Gbps data transfer rates to achieve optimal performance.

Image 3.1: A visual comparison illustrating the significant speed advantage of 20Gbps USB 3.2 Gen 2x2 over 5Gbps USB 3.2 Gen 1.

3.2 Driver fifi sori

For Windows 8/10/11 and Linux, the card is typically plug-and-play, meaning the operating system will automatically install the necessary drivers upon first boot after installation. No manual driver installation is usually required.

4. Itọju

Proper maintenance ensures the longevity and optimal performance of your Inateck Redcomets U27 card.

• Jeki mimọ: Periodically open your computer case and use compressed air to gently remove dust accumulation from the card and surrounding components. Dust can impede airflow and lead to overheating.
• Awọn isopọ to ni aabo: Ensure the card remains firmly seated in its PCIe slot. Loose connections can cause intermittent issues or performance degradation.
• Idaabobo ESD: The card features built-in ESD (Electrostatic Discharge) protection. However, always handle the card by its edges and avoid touching the gold contacts or components directly to prevent static damage during installation or handling.


Àwòrán 4.1: Àwòrán inú view of the card's circuitry, illustrating the over-current and ESD protection mechanisms that safeguard connected devices from potential damage.

5. Laasigbotitusita

If you encounter issues with your Inateck Redcomets U27 card, refer to the following troubleshooting tips:

5.1 Card Not Detected or Not Functioning

• Ṣayẹwo Ibujoko: Ensure the card is fully and securely seated in the PCIe slot. Power off your PC, open the case, and gently press down on the card until it clicks into place.
• Try Another Slot: If available, try installing the card in a different PCIe slot to rule out a faulty motherboard slot.
• Jẹrisi Ibamu: Confirm your operating system is Windows 8/10/11 or Linux. The card is not compatible with Windows 7 or macOS.
• Ṣayẹwo Oluṣakoso ẹrọ (Windows): Open Device Manager and look for any unknown devices or devices with error symbols under "Universal Serial Bus controllers" or "Other devices." If found, try updating the driver (though typically automatic).

5.2 Awọn iyara Gbigbe Data lọra

• PCIe Iho bandiwidi: While the card works in x4, x8, or x16 slots, ensure it is installed in a PCIe 3.0 or 4.0 x16 slot for optimal 20 Gbps performance. Installing in a lower bandwidth slot (e.g., PCIe 2.0 x1) will limit the speed.
• USB Cable Quality: Use a high-quality USB-C to USB-C cable specifically rated for 20 Gbps (USB 3.2 Gen 2x2) or higher. Lower quality or older cables may limit speeds to 5 Gbps or 10 Gbps.
• Connected Device Capability: Ensure the external device (e.g., SSD enclosure, external drive) connected to the card also supports USB 3.2 Gen 2x2 (20 Gbps) speeds. The overall transfer speed will be limited by the slowest component in the chain.
• Motherboard Configuration: Some motherboards may share PCIe lanes. Refer to your motherboard manual to ensure the chosen PCIe slot has dedicated bandwidth and is not sharing lanes with other components that could reduce performance.

6. Awọn pato

7. Atilẹyin ọja ati Support

7.1 atilẹyin ọja Alaye

For detailed warranty information regarding your Inateck Redcomets U27 PCIe USB 3.2 Gen 2x2 Card, please refer to the official Inateck website or the warranty card included with your product packaging. Warranty terms and conditions may vary by region and purchase date.

7.2 Imọ Support

If you require technical assistance, have questions about installation, or need further troubleshooting, please visit the official Inateck support webO le ri awọn ibeere ti a beere nigbagbogbo, awọn igbasilẹ awakọ (ti o ba wulo), ati alaye olubasọrọ fun iṣẹ alabara nibẹ.

Inateck Official Webojula: www.inateck.com
