1. Ifihan
O ṣeun fun riraasing the LENRUE A15 Bluetooth Speaker. This portable wireless speaker is designed to deliver high-quality audio with deep bass, extended playtime, and robust waterproof capabilities, making it ideal for both home and outdoor use. This manual provides detailed instructions on how to set up, operate, and maintain your speaker to ensure optimal performance and longevity.
2. Ọja Ipariview
The LENRUE A15 speaker features a durable design with intuitive controls and a convenient carrying strap. Its IPX7 waterproof rating allows for use in various environments, including near water.
Nọmba 2.1: Iwaju view of the LENRUE A15 Bluetooth Speaker, showcasing its sleek black design and water resistance.
2.1. Package Awọn akoonu
- Agbọrọsọ Bluetooth LENRUE A15 1 x
- 1 x Itọsọna olumulo
- 1 x Okun Ngba agbara USB
- 1 x Okun AX
2.2. Awọn iṣẹ bọtini
| Bọtini | Išẹ |
|---|---|
| Bọtini agbara (Aami agbara) | Tẹ mọlẹ lati fi agbara tan/pa a. Tẹ kukuru lati mu ṣiṣẹ/duro. |
| Bọtini Ipo (M) | Short press to switch between Bluetooth, TF Card, and AUX modes. |
| Iwọn didun isalẹ (-) | Tẹ kukuru lati dinku iwọn didun. Tẹ gun fun orin iṣaaju. |
| Iwọn didun soke (+) | Tẹ kukuru lati mu iwọn didun pọ si. Tẹ gun fun orin atẹle. |
| Ṣiṣẹ / Sinmi (Mu aami / Sinmi duro) | Short press to play/pause. (Note: This function is often integrated with the Power button on some models, refer to specific product for confirmation). |
| Bass + Bọtini (Bass+) | Short press to activate/deactivate Bass Boost mode. |
3. Eto ati Ibẹrẹ Lilo
3.1. Gbigba agbara Agbọrọsọ
Before first use, fully charge the speaker. Connect the provided USB charging cable to the speaker's charging port and the other end to a USB power adapter (not included) or a computer's USB port. The charging indicator light will show charging status and turn off when fully charged. A full charge takes approximately 24 hours.
3.2. Agbara Tan / Paa
- To power on: Press and hold the Power button for 2-3 seconds until you hear an audible prompt.
- To power off: Press and hold the Power button for 2-3 seconds until you hear an audible prompt.
3.3. Sisopọ Bluetooth
The speaker will automatically enter Bluetooth pairing mode when powered on for the first time or if no device is connected. The Bluetooth indicator light will flash rapidly.
- Rii daju pe Bluetooth ẹrọ rẹ ti ṣiṣẹ.
- Wa fun "LENRUE A15" in your device's Bluetooth settings.
- Select "LENRUE A15" to connect. Once connected, the Bluetooth indicator light will remain solid, and you will hear a confirmation sound.
Agbọrọsọ yoo tun sopọ laifọwọyi si ẹrọ ti o so pọ to kẹhin nigbati o ba wa ni tan, ti o ba wa.
Nọmba 3.1: The LENRUE A15 speaker demonstrating its versatile connectivity with various Bluetooth-enabled devices.
3.4. Sitẹrio Alailowaya otitọ (TWS) Sisopọ
TWS allows you to pair two LENRUE A15 speakers together for a true stereo sound experience.
- Rii daju pe awọn agbohunsoke mejeeji wa ni titan ati pe ko sopọ si eyikeyi ẹrọ Bluetooth.
- On one speaker (this will be the primary speaker), double-press the Power button. You will hear a prompt indicating TWS pairing mode.
- The primary speaker will automatically search for the secondary speaker. Once connected, both speakers will emit a confirmation sound, and their Bluetooth indicator lights will synchronize.
- Ní báyìí, so ẹ̀rọ rẹ pọ̀ mọ́ agbọrọsọ àkọ́kọ́ nípasẹ̀ Bluetooth gẹ́gẹ́ bí a ti ṣàlàyé rẹ̀ ní Apá 3.3.
Nọmba 3.2: Two LENRUE A15 speakers set up for True Wireless Stereo, providing a wider soundstage.
4. Awọn ilana Iṣiṣẹ
4.1. Ti ndun Orin
- Ṣiṣẹ/Daduro: Kukuru tẹ bọtini agbara.
- Iṣakoso iwọn didun: Short press the '+' button to increase volume, '-' button to decrease volume.
- Orin t’okan: Tẹ bọtini '+' gun.
- Tẹlẹ Orin: Tẹ bọtini '-' gun.
- Baasi didn: Short press the Bass+ button to toggle bass enhancement.
Nọmba 4.1: The internal components of the LENRUE A15 speaker, highlighting its dual high-performance drivers for rich sound and deep bass.
4.2. Ọwọ-Ọfẹ Npe
With the built-in microphone, you can answer calls directly through the speaker when connected to your phone via Bluetooth.
- Idahun Ipe: Kukuru tẹ bọtini agbara.
- Ipe Ipari: Kukuru tẹ bọtini agbara.
- Kọ Ipe: Tẹ bọtini agbara fun igba pipẹ.
- Oluranlọwọ ohun: Short press the Mode (M) button to activate your device's voice assistant (e.g., Siri, Google Assistant, Alexa).
Nọmba 4.2: The LENRUE A15 speaker's hands-free calling and voice assistant integration, allowing for convenient control.
4.3. TF Card Ipo
Fi káàdì TF (MicroSD) pẹ̀lú ohùn MP3 sí i files into the TF card slot. The speaker will automatically switch to TF Card mode and begin playing music. Use the Play/Pause, Volume, and Track buttons as described above.
4.4. Ipo AUX
Connect an external audio device (e.g., MP3 player, computer) to the speaker's AUX-in port using the provided 3.5mm audio cable. The speaker will automatically switch to AUX mode. Volume control can be managed via both the speaker and the connected device.
5. Waterproof Information (IPX7)
The LENRUE A15 speaker is IPX7 rated, meaning it can be submerged in water up to 1 meter (3.3 feet) for up to 30 minutes. This makes it suitable for use by the pool, at the beach, or in the shower.
- Rí i dájú pé a ti ti ibora ibudo gbigba agbara pa dáadáa kí a tó fi omi sí agbọ́hùnsọ̀ náà.
- Do not submerge the speaker in saltwater or other chemicals, as this may damage the device.
- Lẹ́yìn tí o bá ti fi omi sí i, fi aṣọ rírọ nu agbọ́rọ̀sọ náà kí o tó gba agbára tàbí kí o ṣí i.
Nọmba 5.1: The LENRUE A15 speaker's portability and durability, suitable for outdoor adventures and resistant to rain.
6. Itọju ati Itọju
- Fọ agbohunsoke pẹlu asọ, damp asọ. Maṣe lo awọn kẹmika ti o lewu tabi awọn afọmọ abrasive.
- Tọju agbohunsoke ni itura, ibi gbigbẹ nigbati o ko ba lo.
- Avoid exposing the speaker to extreme temperatures (hot or cold) or direct sunlight for prolonged periods.
- Má ṣe gbìyànjú láti tú tàbí tún agbọ́rọ̀sọ náà ṣe fúnra rẹ, nítorí pé èyí yóò sọ àtìlẹ́yìn náà di òfo.
7. Laasigbotitusita
| Isoro | Owun to le Solusan |
|---|---|
| Agbọrọsọ ko ni agbara lori. | Rí i dájú pé agbọ́hùnsọ̀ náà ti gba agbára tán pátápátá. So mọ́ orísun agbára kí o sì tún gbìyànjú lẹ́ẹ̀kan sí i. |
| Ko le so pọ nipasẹ Bluetooth. |
|
| Ko si ohun tabi iwọn kekere. |
|
| TWS sisopọ kuna. |
|
| Iparun ohun. |
|
8. Awọn pato
| Ẹya ara ẹrọ | Ẹ̀kúnrẹ́rẹ́ |
|---|---|
| Orukọ awoṣe | KML-0015 |
| Agbọrọsọ o wu Power | 20 Wattis |
| Audio Driver Iwon | 40 millimeters |
| Asopọmọra Technology | Bluetooth 5.0 |
| Bluetooth Ibiti | Titi di 100 ẹsẹ (isunmọ 30 mita) |
| Omi Resistance Ipele | IPX7 (Mabomire) |
| Igbesi aye batiri | Titi di Awọn wakati 20 (ni iwọn 50%) |
| Agbara Batiri | 7200 mAh |
| Akoko gbigba agbara | Isunmọ. Awọn wakati 24 |
| Awọn iwọn Ọja (LxWxH) | 5.91" x 1.98" x 2.76" (15cm x 5cm x 7cm) |
| Iwọn Nkan | 350 Giramu (12.3 iwon) |
| Gbohungbohun | Built-in (for Hands-Free Calling) |
| Awọn ipo atilẹyin | Bluetooth, TF Card, AUX |
| Pataki Awọn ẹya ara ẹrọ | Bass Boost, Portable, TWS Pairing |
9. Atilẹyin ọja ati Support
The LENRUE A15 Bluetooth Speaker comes with a limited warranty. For detailed warranty information, product support, or technical assistance, please refer to the contact information provided with your purchase or visit the official LENRUE website. We offer hassle-free 7x24 hours after-sale service.
