BRPOM Car Jump Starter User Manual

Ọrọ Iṣaaju

The BRPOM Car Jump Starter (Model BM501) is a powerful and versatile portable device designed to jump-start 12V vehicles with dead batteries. It features a 6000A peak current and a 26800mAh capacity, capable of starting all gas engines and up to 10L diesel engines. Beyond jump-starting, it functions as a portable power bank for electronic devices and includes an emergency LED flashlight with multiple modes. This manual provides essential information for safe and effective use, maintenance, and troubleshooting.

Image: The BRPOM Car Jump Starter, its smart jumper cables, USB-C charging cable, and a compact carrying case.

Alaye Aabo

IKILO: Read all safety warnings and instructions before using this product. Failure to follow the warnings and instructions may result in electric shock, fire, and/or serious injury.

• Always ensure proper polarity connection (red clamp si rere, dudu clamp to negative) to avoid sparks or damage.
• Maṣe fo-bẹrẹ batiri tio tutunini.
• Maa ko so rere ati odi clamps papọ.
• Jeki kuro ni arọwọto awọn ọmọde.
• Do not expose the device to extreme temperatures (outside -20℃ to 60℃) or moisture.
• Fully charge the unit before first use and periodically to maintain battery health.
• Remove the jump starter from the vehicle battery within 30 seconds after the engine starts.

Package Awọn akoonu

Daju pe gbogbo awọn nkan wa ati ni ipo ti o dara nigbati ṣiṣi package naa:

• BRPOM Car Jump Starter (Model BM501)
• Smart Jumper Cables with Digital Display
• USB-C Ngba agbara Cable
• Afowoyi Olumulo (iwe-ipamọ yii)
• Ọran ipamọ

Image: All components included in the BRPOM Car Jump Starter package, neatly arranged.

Ọja Pariview

The BRPOM BM501 is engineered for reliability and convenience. Key features include:

• Ti o ga julọ lọwọlọwọ: 6000A peak current for powerful jump-starting.
• Agbara Batiri nla: 26800mAh battery, capable of up to 50 jump starts on a single charge.
• Ibamu fun Ẹ̀rọ Gbogbo-gbò: Suitable for all 12V gas engines and up to 10L diesel engines.
• Multi-functional LED Flashlight: Features lighting, flash, and SOS modes for emergencies, usable for up to 48 hours continuously.
• Iṣẹ Bank Power: Two smart USB output ports (including 18W Quick Charge) to rapidly charge phones and tablets.
• Idaabobo Abo To Ti Ni Ilọsiwaju: Smart jumper cables with 8 built-in protections (short circuit, overcharge, over-discharge, reverse connection, reverse polarity, overcurrent, over-heat) and visible alarms.
• Kompasi ti a ṣe sinu rẹ: For navigation during outdoor adventures.

Image: The jump starter's integrated LED flashlight demonstrating its multiple illumination and warning modes.

Image: The jump starter acting as a power bank, charging a tablet and a smartphone.

Image: Illustration of the smart jumper cables' multiple protection features, ensuring safe operation.

Ṣeto

1. Idiyele Ibẹrẹ: Before first use, fully charge the BRPOM Car Jump Starter. Connect the USB-C charging cable to the device's Type-C input port and a compatible USB wall adapter (not included). The battery indicator lights will show charging progress. A full charge typically takes about 4.5 hours.
2. Ṣayẹwo Ipele Batiri: Press the power button once to check the current battery level. Ensure at least three indicator lights are solid for optimal jump-starting performance.
3. Tọju daradara: After charging, store the jump starter and all accessories in the provided storage case in a cool, dry place.

Awọn ilana Iṣiṣẹ

Lọ Bibẹrẹ Ọkọ rẹ

1. Step 1: Insert Jumper Cable: Insert the blue plug of the smart jumper cable into the jump starter's 12V output port. The digital display on the smart cable will show the working status.
2. Step 2: Connect Clamps: So pupa clamp to the positive (+) terminal of the vehicle's dead battery and the black clamp to the negative (-) terminal. The smart cable's display will indicate a correct connection.
3. Step 3: Start Engine: Lọ sinu ọkọ rẹ ki o si tan ẹrọ naa.
4. Step 4: Remove Clamps: Once the engine starts, immediately remove the smart jumper cables from the vehicle battery within 30 seconds. Then, unplug the smart cable from the jump starter.

Image: Step-by-step guide illustrating the process of jump-starting a car with the device.

Lilo bi Bank Power

Connect your electronic devices (smartphones, tablets, etc.) to the USB output ports on the jump starter using their respective charging cables. The device will automatically begin charging.

Using the Emergency Flashlight

Press and hold the power button for 3 seconds to turn on the LED flashlight. Press the power button repeatedly to cycle through the different modes: lighting, flash, and SOS. To turn off the flashlight, press and hold the power button again.

Itoju

• Gbigba agbara deede: To prolong battery life, fully charge the jump starter every 3-6 months, even if not in use. It has an extreme low self-discharge rate, allowing it to standby for up to 12 months.
• Ninu: Nu ẹrọ naa ki o si fiamps with a dry, soft cloth after each use. Do not use harsh chemicals or abrasive materials.
• Ibi ipamọ: Store the unit in its carrying case in a cool, dry environment, away from direct sunlight, heat sources, and moisture.

Laasigbotitusita

Awọn pato

• Awoṣe: BM501
• Tente oke Lọwọlọwọ: 6000A
• Agbara Batiri: 26800mAh
• Bẹrẹ Voltage: 12V
• Ibamu Enjini: All Gas Engines, up to 10L Diesel Engines
• Iru-C Iṣawọle: 5V/2A, 9V/2A (Full charge in ~4.5 hours)
• USB Output 1 (Quick Charge): 5V/3A, 9V/2A, 12V/1.5A
• Okun USB 2: 5V/2.1A
• Iwọn Iṣiṣẹ: -20 ℃ si 60 ℃ (-4 si 140 ℉)
• Awọn iwọn: 4.1"D x 5.4"W x 10"H
• Ìwọ̀n Nkan: 2.44 iwon

Image: The jump starter's robust performance across a wide range of temperatures.

Atilẹyin ọja ati Support

For warranty information and customer support, please refer to the contact details provided on the product packaging or visit the official BRPOM webojula. Tọju iwe-ẹri rira rẹ bi ẹri rira fun awọn iṣeduro atilẹyin ọja.
