1. Ifihan
Thank you for choosing the DAITSU ADD-20XB Dehumidifier. This manual provides essential information for the safe and efficient operation, installation, and maintenance of your appliance. Please read this manual thoroughly before using the dehumidifier and retain it for future reference.
The DAITSU ADD-20XB is designed to reduce excess humidity in your indoor environment, contributing to a more comfortable and healthier living space. It features a compact design, an integrated display, and various functions for optimal humidity control.
2. Alaye Aabo
Jọwọ tẹle awọn iṣeduro aabo wọnyi lati yago fun ipalara tabi ibajẹ si ẹrọ naa:
- Always connect the dehumidifier to a grounded power outlet with the correct voltage.
- Ma ṣe ṣiṣẹ ẹyọ naa pẹlu okun agbara ti o bajẹ tabi pulọọgi.
- Keep the appliance away from water and other liquids. Do not immerse it.
- Ensure adequate ventilation around the unit. Do not block air inlets or outlets.
- Ma ṣe fi nkan sii sinu awọn atẹgun atẹgun.
- Unplug the unit before cleaning, maintenance, or when not in use for extended periods.
- Ohun elo yii kii ṣe ipinnu fun lilo nipasẹ awọn eniyan (pẹlu awọn ọmọde) pẹlu idinku ti ara, imọlara, tabi awọn agbara ọpọlọ, tabi aini iriri ati imọ, ayafi ti wọn ba ti fun wọn ni abojuto tabi itọnisọna nipa lilo ohun elo nipasẹ eniyan ti o ni iduro fun aabo wọn. .
- Awọn ọmọde yẹ ki o wa ni abojuto lati rii daju pe wọn ko ṣere pẹlu ohun elo naa.
3. Ọja Ipariview
The DAITSU ADD-20XB Dehumidifier is a white, compact, floor-standing unit designed for efficient moisture removal. It features an intuitive control panel on the top surface and a large capacity water tank.
olusin 3.1: Iwaju view of the DAITSU ADD-20XB Dehumidifier. This image shows the sleek white design and the DAITSU brand logo prominently displayed on the front panel.
3.1. Awọn eroja akọkọ
- Ibi iwaju alabujuto: Located on the top surface, with an integrated digital display and touch buttons.
- Wiwọle/Olugbafẹfẹ: Vents for drawing in humid air and expelling dry air.
- Omi omi: Removable tank for collecting condensed water.
- Ibudo Idomi Ti nlọ lọwọ: For connecting a hose for continuous water drainage.
- Mu: Integrated handle for easy mobility.
olusin 3.2: Isunmọ view of the control panel. This image highlights the digital display and various control buttons for operating the dehumidifier.
3.2. Awọn iṣẹ Igbimọ Iṣakoso
- Bọtini agbara: Yipada ẹyọ naa tan tabi pa.
- Bọtini Ipo: Selects operating modes (e.g., Dehumidification, Laundry Mode).
- Humidity Adjustment Buttons: Increases or decreases the desired humidity level.
- Bọtini Aago: Ó ń ṣètò aago tí a fi ń tan ara ẹni tàbí tí a fi ń pa ara ẹni.
- Bọtini Iyara Fan: Ṣatunṣe iyara afẹfẹ.
- Iṣafihan Iṣọkan: Ó ń fi ọriniinitutu lọwọlọwọ hàn, ó ń ṣètò ọriniinitutu, ètò aago, àti àwọn kódì àṣìṣe.
4. Eto
4.1. Unpacking
- Farabalẹ yọ dehumidifier kuro ninu apoti rẹ.
- Yọ gbogbo awọn ohun elo iṣakojọpọ kuro, pẹlu eyikeyi awọn fiimu aabo tabi awọn teepu.
- Ṣe àyẹ̀wò ẹ̀rọ náà fún àmì ìbàjẹ́ èyíkéyìí. Tí ó bá bàjẹ́, má ṣe ṣiṣẹ́ kí o sì kan sí olùrànlọ́wọ́ oníbàárà.
4.2. Ifiweranṣẹ
- Place the dehumidifier on a firm, level surface capable of supporting its weight.
- Ensure there is at least 20 cm (8 inches) of clear space around the air inlet and outlet for proper airflow.
- Avoid placing the unit near heat sources, in direct sunlight, or in areas with excessive dust.
- Fun iṣẹ ṣiṣe to dara julọ, pa gbogbo awọn ilẹkun ati awọn ferese ninu yara nibiti ẹrọ mimu ti n ṣiṣẹ.
4.3. Asopọ agbara
Plug the power cord into a suitable grounded electrical outlet. Ensure the voltage ibaamu awọn pato ti awọn kuro.
5. Awọn ilana Iṣiṣẹ
5.1. Ipilẹ isẹ
- Tẹ awọn Bọtini agbara to turn on the dehumidifier. The display will show the current room humidity.
- Lo awọn Humidity Adjustment Buttons (Up/Down arrows) to set your desired humidity level. The recommended range is typically between 40% and 60% relative humidity.
- The unit will automatically start dehumidifying until the set humidity level is reached, then it will cycle on and off to maintain it.
5.2. Aṣayan Ipo
Tẹ awọn Bọtini Ipo to cycle through available operating modes:
- Ipò Ìtújáde: Standard operation to reduce room humidity.
- Laundry Mode (Dry Clothes): Designed to quickly dry clothes by continuously running the dehumidifier at a high fan speed.
5.3. Iṣẹ Aago
Tẹ awọn Bọtini Aago to set an auto-on or auto-off time. Use the humidity adjustment buttons to set the desired hours (1-24). The timer indicator will illuminate when active.
5.4. Fan Speed Atunṣe
Tẹ awọn Bọtini Iyara Fan to select between different fan speeds (e.g., Low, High). Higher fan speed results in faster dehumidification but may produce more noise.
5.5. Water Tank and Continuous Drainage
- Omi omi: When the water tank is full, the unit will automatically shut off, and a Full ojò Alert will activate. Carefully remove the tank, empty the collected water, and reinsert it securely.
- Imudanu Tesiwaju: For extended operation without emptying the tank, connect a suitable drainage hose (not included) to the continuous drainage port at the back of the unit. Ensure the hose is sloped downwards to allow gravity drainage into a floor drain or larger container.
Olusin 5.1: Pariview of key features including high dehumidification capacity (20L/day), automatic airflow, laundry mode, large capacity water tank, timer, easy mobility, and full tank alert.
6. Itọju
Itọju deede ṣe idaniloju iṣẹ ṣiṣe ti o dara julọ ati fa gigun igbesi aye ti dehumidifier rẹ.
6.1. Ninu Ajọ Afẹfẹ
Ajọ afẹfẹ yẹ ki o di mimọ ni gbogbo ọsẹ meji tabi diẹ sii nigbagbogbo da lori lilo ati didara afẹfẹ.
- Pa a kuro ki o yọọ kuro ni ẹrọ mimu kuro.
- Wa àlẹ̀mọ́ afẹ́fẹ́ náà kí o sì yọ ọ́ kúrò (nígbà gbogbo ní ẹ̀yìn tàbí ẹ̀gbẹ́ ẹ̀rọ náà).
- Wẹ àlẹmọ pẹlu gbona, omi ọṣẹ. Fi omi ṣan daradara ki o jẹ ki o gbẹ patapata ṣaaju ki o to fi sii.
- Do not use a dishwasher or expose the filter to direct sunlight for drying.
6.2. Ninu Omi Omi
Mọ ojò omi nigbagbogbo lati ṣe idiwọ mimu ati imuwodu idagbasoke.
- Yọ omi ojò lati kuro.
- Fọ ojò pẹlu omi tutu ati omi gbona.
- Fi omi ṣan daradara ki o gbẹ ṣaaju ki o to gbe e pada sinu dehumidifier.
6.3. Ita Cleaning
Mu ese ita kuro pẹlu asọ, damp asọ. Ma ṣe lo awọn kẹmika ti o lewu, awọn afọmọ abrasive, tabi awọn nkanmimu.
6.4. Ibi ipamọ
Ti o ba tọju ẹyọ naa fun igba pipẹ:
- Ṣofo ati nu omi ojò.
- Mọ àlẹmọ afẹfẹ.
- Fi ipari si okun agbara daradara.
- Tọju ẹyọ naa ni pipe ni itura, aye gbigbẹ, kuro lati orun taara ati awọn iwọn otutu to gaju.
7. Laasigbotitusita
Ṣaaju ki o to kan si atilẹyin alabara, jọwọ wo itọsọna laasigbotitusita atẹle yii fun awọn ọran ti o wọpọ:
| Isoro | Owun to le Fa | Ojutu |
|---|---|---|
| Ẹka ko ni tan-an | Ko si ipese agbara Okun agbara ko ṣafọ sinu aabo | Check power outlet and plug connection Ensure the outlet is functional |
| A ko gba omi ti a kojọ | Room humidity is too low Afẹfẹ àlẹmọ ti wa ni dí Iwọn otutu ti lọ silẹ pupọ Omi omi ko fi sori ẹrọ daradara | Increase desired humidity setting Mọ àlẹmọ afẹfẹ Operate in a warmer environment (above 5°C) Ensure water tank is correctly seated |
| Unit jẹ alariwo | Kuro ko lori kan ipele dada Afẹfẹ àlẹmọ ti wa ni dí Àwọn èròjà inú tí ń mì tìtì | Gbe sori alapin, dada iduroṣinṣin Mọ àlẹmọ afẹfẹ This may be normal during operation; if excessive, contact support |
| Water tank full indicator on, but tank is not full | Leefofo yipada aiṣedeede Ojò ko joko daradara | Remove and reinsert the water tank firmly Kan si atilẹyin alabara ti iṣoro naa ba tẹsiwaju |
| Automatic defrost function active | Coils are freezing due to low temperature | This is normal operation. The unit will pause dehumidification and run the fan to melt frost. Dehumidification will resume automatically. |
8. Awọn pato
| Ẹya ara ẹrọ | Sipesifikesonu |
|---|---|
| Nọmba awoṣe | ADD-20XB (3NDA0044) |
| Brand | DAITSU |
| Agbara Dehumidification | 20 liters / ọjọ |
| Àwọ̀ | Funfun |
| Ohun elo | Alloy Irin |
| Iwọn | 13 kilo |
| Pataki Awọn ẹya ara ẹrọ | Adjustable Humidity Control, Automatic Defrost, Water Level Indicator, Continuous Drainage |
| Agbara Kilasi | A++ sí E |
9. Atilẹyin ọja ati Support
For warranty information, please refer to the documentation provided at the time of purchase. Keep your proof of purchase for any warranty claims.
If you encounter issues not covered in this manual or require further assistance, please contact DAITSU customer support. Contact details can typically be found on the manufacturer's webojula tabi risiti rira rẹ.
