Nikko Radio Control 1:12 Omni X RC Car Instruction Manual

Ọrọ Iṣaaju

O ṣeun fun riraasing the Nikko Radio Control 1:12 Omni X RC Car. This manual provides essential information for the safe and optimal operation, setup, and maintenance of your new remote-controlled vehicle. Please read this manual thoroughly before use and retain it for future reference.

Alaye Aabo

• Iṣeduro ọjọ ori: This product is suitable for users aged 6 years and up. Adult supervision is recommended for younger users.
• Aabo Batiri: Use only the specified 6.4V LiFePo4 battery and USB quick charger. Do not attempt to charge non-rechargeable batteries. Do not short-circuit, disassemble, or expose batteries to extreme temperatures or fire.
• Ayika Ṣiṣẹ: Operate the RC car in open, clear areas away from people, pets, and obstacles. Avoid operating near water, roads, or in crowded spaces.
• Ìjánu: The 2.4GHz frequency minimizes interference, but avoid operating multiple RC vehicles on the same frequency band in very close proximity to prevent signal conflicts.
• Ninu: Disconnect the battery before cleaning. Use a dry cloth to wipe the vehicle. Do not immerse in water.

Package Awọn akoonu

Daju pe gbogbo awọn nkan ti a ṣe akojọ rẹ si isalẹ wa ninu package rẹ:

• Nikko 1:12 Omni X RC Car
• Latọna jijin Adarí
• 6.4V LiFePo4 Rechargeable Battery Pack (for car)
• USB Quick Charger
• Ilana Afowoyi (iwe yii)

Image: The Nikko 1:12 Omni X RC Car and its remote controller, displayed within its retail packaging. The car features a black and red design with multi-directional wheels. The remote is black with red buttons. The packaging highlights features like "Full Function," "Multi-Band 10-Player Racing," "USB Powered," "6.4V LiFePo4 Battery USB Quick Charge," "2.4GHz Frequency," "Extreme Drift Technology," "9 MPH / 14 KPH Speed," and "Up to 40 Meters / 131 FT Range."

Ṣeto

1. Gbigba agbara batiri ọkọ ayọkẹlẹ

1. Locate the 6.4V LiFePo4 battery pack and the USB Quick Charger.
2. Connect the battery pack to the USB Quick Charger.
3. Plug the USB charger into any standard USB power source (e.g., computer USB port, USB wall adapter).
4. The charging indicator light on the charger will illuminate (color may vary, refer to charger for specifics).
5. Allow approximately 60-90 minutes for a full charge. The indicator light will change or turn off when charging is complete.
6. Once charged, disconnect the battery from the charger.

2. Installing the Car Battery

1. Rí i dájú pé ẹ̀rọ ìyípadà agbára ọkọ̀ ayọ́kẹ́lẹ́ náà wà ní ipò "PA".
2. Locate the battery compartment on the underside of the Omni X car.
3. Open the battery compartment cover (you may need a small screwdriver).
4. Connect the charged 6.4V LiFePo4 battery pack to the car's battery connector, ensuring correct polarity.
5. Fi batiri naa sinu yara naa pẹlu iṣọra ki o si pa ideri naa mọ lailewu.

3. Fifi Awọn Batiri Oluṣakoso Latọna jijin sii

(Note: Remote controller batteries are typically not included and require 2x AA batteries.)

1. Wa ibi ipamọ batiri naa ni ẹhin oludari latọna jijin.
2. Ṣii ideri iyẹwu batiri naa.
3. Insert 2x AA batteries, observing the correct polarity (+/-) as indicated inside the compartment.
4. Pa ideri batiri naa ni aabo.

4. Sísopọ̀ Olùdarí Latọna jijin

The Nikko Omni X uses 2.4GHz frequency for automatic pairing.

1. Turn on the RC car using the power switch.
2. Tan oluṣakoso latọna jijin.
3. The car and remote should automatically pair within a few seconds. An indicator light on the remote (if present) may stop flashing or turn solid to confirm pairing.
4. Tí ìsopọ̀ náà bá kùnà, pa àwọn ẹ̀rọ méjèèjì kí o sì tún ṣe iṣẹ́ náà.

Awọn ilana Iṣiṣẹ

Awọn iṣakoso ipilẹ

• Siwaju/Sẹhin: Use the left joystick (or trigger) to move the car forward or backward.
• Ìdarí (Òsì/Ọ̀tún): Use the right joystick (or wheel) to steer the car left or right.
• Iṣẹ ni kikun: The Omni X offers full directional control, allowing precise movements.

Extreme Drift Technology

The Omni X is equipped with specialized wheels and "Extreme Drift Technology" allowing for unique sideways and diagonal movements, as well as 360-degree spins. Experiment with combinations of forward/backward and steering controls to master these drift maneuvers.

Multi-Band 10-Player Racing

Thanks to its 2.4GHz frequency, up to 10 Nikko Omni X vehicles can be operated simultaneously without interference, allowing for multi-player racing and interaction. Ensure each car and remote is paired individually before starting a multi-player session.

Performance Loriview

• Iyara: Titi di 9 MPH (14 KPH)
• Ibiti: Titi de awọn mita 40 (131 ẹsẹ)

Itoju

• Ninu: Use a soft, dry cloth to wipe down the car and remote after each use. Do not use water or chemical cleaners. Remove any debris from the wheels and chassis.
• Ibi ipamọ: When not in use, turn off both the car and the remote. Remove batteries from the remote controller if storing for extended periods. Store the vehicle in a cool, dry place away from direct sunlight and extreme temperatures.
• Itọju Batiri: Always fully charge the LiFePo4 battery before storage and recharge it periodically (every 3-6 months) to maintain battery health if not used regularly.

Laasigbotitusita

Awọn pato

Atilẹyin ọja ati Support

Nikko products are manufactured to high-quality standards. For warranty information, technical support, or replacement parts, please refer to the contact information provided on the product packaging or visit the official Nikko webAaye ayelujara. Jọwọ mu nọmba awoṣe rẹ (10052) ṣetan nigbati o ba kan si atilẹyin.

Webojula: www.nikko-rc.com (Eksample ọna asopọ, ṣayẹwo oju opo wẹẹbu osise)
