Ọrọ Iṣaaju
This manual provides comprehensive instructions for the safe and efficient use of your BolaButty Wireless Outdoor Rock Bluetooth Speaker (Model S311). Please read this manual thoroughly before operating the device and retain it for future reference.
Alaye Aabo
- Do not expose the speaker to extreme temperatures or direct sunlight for prolonged periods beyond its operational limits.
- Ensure the charging port cover is securely closed when not charging to maintain IPX7 waterproof rating.
- Má ṣe gbìyànjú láti tú agbọ́rọ̀sọ náà ká, tún un ṣe, tàbí yí i padà. Èyí yóò sọ àtìlẹ́yìn náà di òfo, ó sì lè fa ìbàjẹ́ tàbí ìpalára.
- Jeki agbohunsoke kuro ni ṣiṣi ina tabi awọn orisun ooru.
- Lo okun gbigba agbara ti a pese nikan ati ohun ti nmu badọgba.
- Sọ ọja naa ni ifojusọna ni ibamu si awọn ilana agbegbe.
Package Awọn akoonu
Jẹrisi pe gbogbo awọn ohun kan wa ninu package:
- 1 x BolaButty Wireless Outdoor Rock Bluetooth Speaker
- 1 x Okun gbigba agbara
- 1 x Itọsọna Ibẹrẹ kiakia
Ọja Pariview
The BolaButty Wireless Outdoor Rock Bluetooth Speaker is designed to blend seamlessly into outdoor environments while delivering high-quality audio. It features a durable, weather-resistant construction and a solar charging panel for extended use.
olusin 1: Iwaju view of the BolaButty Wireless Outdoor Rock Bluetooth Speaker, showcasing its rock-like appearance and speaker grille.
Awọn ẹya pataki:
- Ohùn Alagbara: Delivers 30W of sound output, with the ability to combine two units for 60W stereo sound.
- Agbara Oorun: Integrated solar panel for convenient recharging, extending battery life.
- IPX7 mabomire: Designed to withstand immersion in water up to 1 meter for 30 minutes, making it suitable for various weather conditions.
- Bluetooth 5.3 Asopọmọra: Ensures stable and long-range wireless connection up to 33 feet (10 meters).
- Igbesi aye batiri gigun: Up to 36 hours of playback at 50% volume on a single charge.
- Apẹrẹ ti o tọ: Constructed from Acrylonitrile Butadiene Styrene (ABS), Aluminum, and Thermoplastic Polyurethane (TPU) for outdoor resilience.
olusin 2: An exploded view illustrating the internal speaker components and the powerful sound projection capability of the device.
Figure 3: Two rock speakers seamlessly integrated into a garden landscape, highlighting their compact dimensions (approximately 12.4"D x 10.9"W x 11.4"H).
Nọmba 4: Alaye view of the solar panel on top of the speaker, indicating its high energy conversion efficiency.
Ṣeto
Gbigba agbara ni ibẹrẹ
Before first use, it is recommended to fully charge the speaker using the provided charging cord. The speaker can also be charged via its integrated solar panel when exposed to direct sunlight. A full charge typically takes approximately 2 hours via cable.
Asopọ Bluetooth
- Ensure the speaker is powered on and in Bluetooth pairing mode. A voice prompt "Bluetooth mode" will confirm this.
- Lori ẹrọ alagbeka rẹ (foonuiyara, tabulẹti, ati bẹbẹ lọ), mu Bluetooth ṣiṣẹ ki o wa awọn ẹrọ to wa.
- Select "Rock Stone" from the list of devices.
- Once connected, you will hear a "connected" voice prompt.
Syncing Two Rock Stone Bluetooth Speakers (Stereo Pairing)
To achieve a 60W stereo sound experience, you can pair two BolaButty Rock Stone speakers together. Follow these steps:
Figure 5: Step-by-step visual guide for pairing two Rock Stone Bluetooth speakers for stereo sound.
- Igbesẹ 1: Long press the power button on one of the two speakers. Ensure the other speaker and your phone's Bluetooth are powered off. You will hear "power on" followed by "Bluetooth mode".
- Igbesẹ 2: Long press the power button on the second speaker. Ensure your phone's Bluetooth is still powered off. Wait a few seconds until you hear a prompt tone, then "connected".
- Igbesẹ 3: Now, enable Bluetooth on your phone and tap "Rock Stone" to pair with the combined speaker system.
Akiyesi: If your phone was previously connected to a single Rock Stone speaker, you need to "forget" or unpair it from your phone's Bluetooth settings before attempting to sync two speakers.
Awọn ilana Iṣiṣẹ
Titan / Paa
- Agbara Tan: Long press the power button until you hear "power on".
- Agbara Pa: Long press the power button until the speaker powers down.
Iṣakoso iwọn didun
Adjust the volume directly from your connected Bluetooth device (smartphone, tablet, etc.).
Sisisẹsẹhin Orin
Once connected via Bluetooth, simply play audio from your device. The speaker will output the sound. Control playback (play/pause, skip tracks) from your connected device.
Solar Charging Operation
The integrated solar panel charges the speaker's internal battery when exposed to direct sunlight. For optimal charging, place the speaker in an area with maximum sun exposure. The solar charging feature helps maintain battery levels during outdoor use, extending playback time.
olusin 6: A sunmọ-soke view of the solar panel, demonstrating its function in charging the speaker's battery.
Itoju
- Ninu: Nu agbọrọsọ nu pẹlu asọ, damp asọ. Ma ṣe lo abrasive ose tabi epo.
- Ibi ipamọ: When not in use for extended periods, store the speaker in a cool, dry place. Ensure it is fully charged before storing to preserve battery health.
- Atako oju ojo: While IPX7 waterproof, it is recommended to avoid leaving the speaker submerged for prolonged periods or exposing it to extremely harsh weather conditions (e.g., blizzards, severe hailstorms) to maximize its lifespan. Ensure the charging port cover is always sealed when not charging.
Laasigbotitusita
| Isoro | Owun to le Fa | Ojutu |
|---|---|---|
| Agbọrọsọ ko ni agbara lori. | Batiri kekere. | Charge the speaker using the provided charging cable or place it in direct sunlight. |
| Ko le so pọ pẹlu ẹrọ Bluetooth. | Bluetooth not enabled on device; speaker not in pairing mode; device too far; previously paired. | Ensure Bluetooth is on and speaker is in pairing mode. Move device closer. If previously paired, "forget" the device in your phone's Bluetooth settings and try again. |
| Ko si ohun lati agbọrọsọ. | Iwọn ti o kere ju; agbọrọsọ ko sopọ; oro orisun ohun. | Increase volume on both speaker and connected device. Ensure speaker is properly connected via Bluetooth. Check audio source on your device. |
| Solar charging not working effectively. | Insufficient sunlight; dirty solar panel. | Place the speaker in direct, unobstructed sunlight. Clean the solar panel surface with a soft, damp asọ. |
Awọn pato
| Ẹya ara ẹrọ | Ẹ̀kúnrẹ́rẹ́ |
|---|---|
| Orukọ awoṣe | S311 |
| Agbọrọsọ Iru | Ita gbangba |
| Asopọmọra Technology | Bluetooth 5.3 |
| Agbọrọsọ Agbara Ijade ti o pọju | 30 Watts (per unit) |
| Ipo Ijade Ohun | Stereo (when two units are paired) |
| Idahun Igbohunsafẹfẹ | 10000 Hz |
| Omi Resistance Ipele | IPX7 mabomire |
| Orisun agbara | Battery Powered, Solar-Powered |
| Batiri Iru | 1D batiri (pẹlu) |
| Ibiti o pọju | 20 Mita (ẹsẹ 65) |
| Awọn iwọn Ọja (LxWxH) | 12.4"D x 10.9"W x 11.4"H |
| Iwọn Nkan | 8.88 iwon |
| Ohun elo | Acrylonitrile Butadiene Styrene (ABS), Aluminum, Thermoplastic Polyurethane (TPU) |
| Àwọ̀ | 1pc-Grey |
| inu ile / ita gbangba Lilo | Ninu ile, ita gbangba |
Atilẹyin ọja ati Support
This BolaButty product comes with a Atilẹyin ọja to lopin. For specific warranty terms and conditions, please refer to the quick start guide included in your package or contact BolaButty customer support.
For technical support, troubleshooting assistance, or warranty claims, please visit the official BolaButty webojú òpó wẹ́ẹ̀bù tàbí kí o kàn sí ẹ̀ka iṣẹ́ oníbàárà wọn. Àwọn ìwífún ìbáṣepọ̀ lè wà lórí àpótí ọjà tàbí lórí ìkànnì ayélujára tí ilé-iṣẹ́ náà wà.
Atilẹyin Ayelujara: Visit the BolaButty Store on Amazon
