1. Ifihan
This manual provides essential instructions for setting up, operating, and maintaining your Tecno Spark 30C 5G smartphone. Please read this manual thoroughly to ensure proper use and to maximize the device's features.
The Tecno Spark 30C 5G is a feature-rich smartphone equipped with a D6300 5G Processor, a 48MP Sony AI Camera, a 5000mAh battery with 18W fast charging support, NFC, IR Remote, and Dolby Atmos sound. It operates on Android 14 and offers IP54 dust and splash resistance.
2. Ẹrọ Loriview
Familiarize yourself with the physical components of your Tecno Spark 30C 5G.
Aworan 2.1: Iwaju view of the Tecno Spark 30C 5G smartphone, showing the display, front camera, and speaker grille.
The device features a large display, a front-facing camera, and various sensors. The rear houses the main camera module and flash.
3. Eto Itọsọna
3.1. Unboxing ati Package Awọn akoonu
Jẹrisi pe package rẹ ni awọn nkan wọnyi ninu:
- Tecno Spark 30C 5G Smartphone
- Okun USB
- SIM Atẹ ejector
- Foonu Case
Note: A power adapter may not be included and might need to be purchased separately. The device supports 18W fast charging.
3.2. Inserting SIM Card and Memory Card
- Wa atẹ kaadi SIM ni ẹgbẹ ti ẹrọ naa.
- Fi SIM atẹ ejector ọpa sinu kekere iho tókàn si awọn atẹ ki o si tẹ rọra titi ti atẹ yoo jade.
- Fi kaadi SIM Nano-SIM rẹ àti/tàbí kaadi microSD (tí ó bá yẹ) sínú àwọn ihò tí a yàn lórí atẹ náà. Rí i dájú pé àwọn ohun tí ó wà lára wúrà náà dojú kọ ìsàlẹ̀.
- Fi iṣọra tun fi atẹ sii sinu foonu titi ti o fi tẹ sinu aaye.
3.3. Ngba agbara ẹrọ
Before first use, fully charge your Tecno Spark 30C 5G.
- So okun USB pọ mọ ibudo gbigba agbara foonu.
- Connect the other end of the USB cable to a compatible 18W power adapter (not included) and plug it into a power outlet.
- Aami batiri loju iboju yoo tọkasi ipo gbigba agbara.
Aworan 3.1: Isalẹ view of the Tecno Spark 30C 5G, showing the USB-C charging port and speaker grille.
3.4. Agbara Titan ati Eto Ibẹrẹ
- Tẹ bọtini agbara naa ki o si mu titi ti aami Tecno yoo fi han.
- Tẹle awọn ilana loju iboju lati pari iṣeto akọkọ, pẹlu yiyan ede, asopọ Wi-Fi, iṣeto akọọlẹ Google, ati awọn eto aabo.
4. Ṣiṣẹ ẹrọ rẹ
4.1. Ipilẹ Lilọ kiri
Your Tecno Spark 30C 5G uses a touchscreen interface. Common gestures include tapping, swiping, pinching, and long-pressing.
Aworan 4.1: The Tecno Spark 30C 5G display showcasing its punch-hole design and 120Hz refresh rate capability.
4.2. Ṣiṣe Awọn ipe ati Fifiranṣẹ Awọn ifiranṣẹ
- Awọn ipe: Fọwọ ba aami foonu, tẹ nọmba sii, ki o tẹ bọtini ipe ni kia kia.
- Awọn ifiranṣẹ: Tẹ aami Ifiranṣẹ naa, bẹrẹ ibaraẹnisọrọ tuntun kan, tẹ olugba naa sii ati ifiranṣẹ naa, lẹhinna firanṣẹ.
4.3. Lilo kamẹra
The Tecno Spark 30C 5G features a 48MP Sony AI Camera for high-quality photography.
- Ṣii ohun elo kamẹra.
- Select your desired mode (e.g., Photo, Video, Portrait).
- Tap the shutter button to capture an image or start/stop recording.
Aworan 4.2: Close-up of the Tecno Spark 30C 5G's rear camera module, highlighting the 48MP Sony AI Camera lens.
4.4. Awọn ẹya ara ẹrọ Asopọmọra
- Nẹtiwọọki 5G: Enjoy high-speed internet connectivity. Ensure your SIM card and plan support 5G.
- Wi-Fi: Sopọ si awọn nẹtiwọki alailowaya nipasẹ Eto> Nẹtiwọọki & intanẹẹti> Wi-Fi.
- Bluetooth: Pair with other Bluetooth devices via Settings > Connected devices > Bluetooth.
- NFC: Use Near Field Communication for contactless payments and quick data transfer. Enable NFC in Settings > Connected devices > Connection preferences > NFC.
- Latọna jijin IR: Utilize the built-in IR Blaster to control compatible home appliances. Access the IR Remote app to set up and manage devices.
4.5. Audio Settings (Dolby Atmos)
Enhance your audio experience with Dolby Atmos. Access settings via Settings > Sound & vibration > Dolby Atmos to customize sound profiles for music, movies, and games.
5. Itọju ati Itọju
5.1. Ninu Rẹ Device
Use a soft, lint-free cloth to clean the screen and body of your phone. Avoid abrasive materials or harsh chemicals. Do not spray cleaners directly onto the device.
5.2. Itọju batiri
Lati pẹ igbesi aye batiri:
- Yago fun awọn iwọn otutu to gaju.
- Má ṣe jẹ́ kí bátírì náà máa gbẹ pátápátá nígbà gbogbo.
- Use the provided or a compatible 18W charger.
5.3. Software imudojuiwọn
Ṣayẹwo nigbagbogbo fun ati fi awọn imudojuiwọn sọfitiwia sori ẹrọ lati rii daju iṣẹ ṣiṣe ati aabo to dara julọ. Lọ si Eto> Eto> Imudojuiwọn eto.
5.4. IP54 Dust and Splash Resistance
The Tecno Spark 30C 5G is rated IP54 for dust and splash resistance. This means it is protected against limited dust ingress and water splashes from any direction. It is not waterproof. Avoid submerging the device in water or exposing it to high-pressure water jets.
6. Laasigbotitusita
Ti o ba pade awọn iṣoro pẹlu ẹrọ rẹ, gbiyanju awọn ojutu wọnyi:
| Isoro | Ojutu |
|---|---|
| Ẹrọ naa ko ṣiṣẹ | Rii daju pe batiri ti gba agbara. Tẹ mọlẹ bọtini Agbara fun o kere ju 10-15 iṣẹju-aaya. |
| Ifihan nẹtiwọki ti ko dara | Ṣayẹwo fifi kaadi SIM sii. Gbe lọ si agbegbe pẹlu agbegbe nẹtiwọki to dara julọ. Tun ẹrọ naa bẹrẹ. |
| Awọn ohun elo kọlu tabi didi | Close background apps. Clear app cache (Settings > Apps > [App Name] > Storage & cache). Restart the device. |
| Batiri n ṣan ni kiakia | Reduce screen brightness. Disable unused features like Wi-Fi, Bluetooth, GPS. Check battery usage in Settings to identify power-hungry apps. |
| Kamẹra ko ṣiṣẹ | Restart the camera app. Clear camera app cache. Restart the phone. |
Tí ìṣòro bá ń bá a lọ, kan si atilẹyin alabara tabi lọ si ile-iṣẹ iṣẹ ti a fun ni aṣẹ.
7. Awọn pato
Key technical specifications for the Tecno Spark 30C 5G:
| Ẹya ara ẹrọ | Ẹ̀kúnrẹ́rẹ́ |
|---|---|
| Eto isesise | Android 14 |
| isise | 6nm D6300 5G Processor |
| Àgbo | 4 GB (Up to 8GB with Memory Fusion) |
| Ibi ipamọ inu | 64 GB (Ti o gbooro nipasẹ microSD) |
| Kamẹra ẹhin | 48MP Sony AI Camera |
| Agbara Batiri | 5000 mAh |
| Gbigba agbara | 18W Yara Gbigba agbara Support |
| Asopọmọra | 5G, Wi-Fi, Bluetooth, NFC, USB |
| Pataki Awọn ẹya ara ẹrọ | IR Remote, Dolby Atmos, IP54 Dust and Splash Resistance |
| Awọn iwọn | 16.5 x 7.7 x 0.8 cm |
| Iwọn | 189 g |
8. Atilẹyin ọja ati Support
8.1. atilẹyin ọja Information
Your Tecno Spark 30C 5G is covered by a limited manufacturer's warranty. Please refer to the warranty card included in your product packaging for specific terms and conditions, including warranty period and coverage details. Keep your proof of purchase for warranty claims.
8.2. Onibara Support
Fun iranlọwọ imọ-ẹrọ, iṣẹ, tabi awọn ibeere siwaju sii, jọwọ kan si atilẹyin alabara Tecno. O le wa alaye olubasọrọ lori Tecno osise. website or through the support section of your device settings.
Manufacturer: G Mobiles India
Fun alaye diẹ sii, ṣabẹwo si osise naa Ile itaja Tecno.
